Tascam VS-R264

UPC/EAN #043774034918 MPN #VS-R264

$1689.00

Save 20.5%, MSRP $2125.00

Financing available

Be the first to write a review

Free shipping in Canada. Conditions

Full HD H.264 streaming, 8 simulcast streams, RTMP/RTSP/HLS, HDMI I/O, SD/USB/internal recording, PoE+, MP4/TS support, REST API, half-rack size

The TASCAM VS-R264 is a professional-grade hardware encoder and decoder designed for Full HD AV over IP streaming, simultaneous recording, and playback. Ideal for commercial installations in corporate, education, house of worship, and security settings, the VS-R264 supports real-time H.264 streaming with resolutions up to 1080p. This compact, stand-alone unit eliminates the need for external computers, delivering robust reliability, multiple streaming options, and seamless integration with common Content Delivery Networks (CDNs) such as YouTube. It supports up to eight simultaneous streams-including RTMP, RTSP, HLS, and multicast protocols-and offers both HDMI and analog audio I/O for versatile connectivity.

What sets the VS-R264 apart is its all-in-one approach: in addition to encoding and streaming, it records video to SD cards, USB drives, or internal storage (up to 17GB), with automatic FTP upload for archiving or repurposing. The unit supports MP4 and TS file formats and features continuous recording by automatically deleting older files when storage is full. Its compact half-rack design is rack-mountable and PoE+ powered, making it easy to install in tight spaces. With support for RESTful API, web-based remote management, and TASCAM's DISCOVERY software, the VS-R264 is an ideal solution for stable, high-quality AV streaming and recording in demanding environments.

Features

All-in-One Streaming Device: Streams, records, encodes, and decodes Full HD video simultaneously without a computer.

Multiple Streaming Protocols: Supports RTMP, RTSP, HLS, RTP, and more for wide compatibility with platforms.

Simultaneous Multiplatform Streaming: Streams to up to three RTMP destinations at once, with backup options included.

Flexible Recording Options: Records to SD cards, USB drives, or internal 17GB storage; supports MP4 and TS formats.

Continuous Recording Feature: Automatically deletes oldest files when storage is full to ensure uninterrupted recording.

Professional Audio Integration: Supports analog and HDMI audio with embedding and de-embedding functions.

Compact, Stand-Alone Design: Half-rack size with included mounting brackets; no PC needed for operation.

Remote Management: Configure and manage the device via web browser or the TASCAM DISCOVERY app.

PoE+ and Ethernet Support: Powered via PoE+ or optional adapter; supports Gigabit Ethernet for stable streaming.

RESTful API for System Integration: Integrates easily into commercial AV systems with control via RESTful API.

Specifications

General Specifications

Full HD hardware encoder decoder and recorder

Standalone unit no external computer required

Simultaneous recording encoding streaming and decoding

Records to USB SD card and 17GB internal storage

MP4 and TS recording formats

Web GUI and TASCAM DISCOVERY app for remote management

RESTful API for integration with control systems

PoE Plus Class 4 and optional AC adapter TASCAM PS P1220E

Dimensions 214 x 44.5 x 136.1 mm

Weight 850 grams

Power consumption 12.2W

Operating temperature 0 to 40 degrees Celsius

Video Specifications

HDMI input HDMI v1.4a Type A

HDMI output HDMI v2.0 Type A

Supported input resolutions up to 1080p 60 fps

Encoding format H.264

Encoding bitrates 500k to 30M bps

Encode scaling resolutions passthrough to 320x180p

Frame rate limiting on off

Key frame interval 0.25 to 16.5 seconds or 3 to 1000 frames

Streaming Specifications

Supported protocols RTMP RTMPS RTSP HLS RTP UDP

Up to 8 simultaneous streams

3 x RTMP RTMPS

1 x RTSP

1 x HLS

2 x RTP UDP Unicast

1 x RTP UDP Multicast

Audio Input and Output Specifications

Balanced input Euroblock +4dBu to +20dBu 10k ohm impedance

Unbalanced input 3.5mm stereo mini jack minus 10dBV to +6dBV 10k ohm impedance

Balanced output Euroblock +4dBu to +20dBu 200 ohm or lower impedance

Unbalanced output 3.5mm stereo mini jack minus 10dBV to +6dBV 200 ohm impedance

Output volume minus infinity to +6dB in 1dB steps

Audio codec AAC 64k to 512k bps 32k 44.1k 48kHz

Recording Specifications

Recording media USB SD SDHC Internal storage

Max internal file size 17GB

Recording formats MPEG2 TS MPEG4

Recording bitrates 500k to 30M bps

Continuous recording with auto file deletion when storage is full

Control and Connectivity

Ethernet RJ45 supports Gigabit 1000BASE T

Supports TCP IP UDP HTTP

USB Type A 4 pin USB 2.0 and USB 3.0

Audio Performance

AD converter distortion 0.002 percent SNR 102dB

DA converter distortion 0.00035 percent SNR 130dB

Analog to HDMI performance frequency response 20Hz to 16.5kHz distortion 0.008 percent SNR 94dB dynamic range 95dB crosstalk 90dB

HDMI to analog performance frequency response 20Hz to 16.5kHz distortion 0.007 percent SNR 113dB balanced 109dB unbalanced dynamic range 96dB crosstalk 100dB

Included Accessories

VS R264 unit

USB flash drive with TASCAM DISCOVERY and manual

Installation brackets x2

Euroblock plugs x4

Cable band kit

Owners manual with warranty
