1:2 Dual Link DVI Distribution Amplifier. One Dual Link DVI Source Splitter to two Dual Link DVI Outputs
The Gefen EXT-DVI-142DLN Dual-link 1:2 DVI DL Distribution Amplifier splits video using a dual link DVI source such as a computer to two DVI dual link outputs such as monitors, without losing picture quality or the high resolution. Multiple1:2 DVI DL units can be cascaded from one to the next to create a flexible Dual Link DVI distribution system that can connect to multiple displays.
Caractéristiques
Split a Dual Link DVI signal to two DVI Dual Link outputs
Allows simultaneous display of source on two screens
Supports Single Link DVI resolutions up to 1920 x 1200, and dual-link up to 3840 x 2400
Auto EQ compensates for any imperfections in the image
Power On indicator
DVI Link indicators
Supports DDWG standard for DVI-compliant monitors
HDCP pass-through on output #1
Spécifications
Maximum Pixel Clock: 2 x 165 MHz
Video Input Connector: (1) DVI-D, 29-pin, female
Video Output Connectors: (2) DVI-D, 29-pin, female
Power On indicator: (1) LED, blue
Link indicators: (2) LED, green
Power Consumption: 5 W (max.)
Power Supply: 5V DC
Operating Temperature: +32 to +104 ÂF (0 to +40 ÂC)
Operating Humidity: 20% to 80% RH, non-condensing
Storage Temperature: -4 to +140 ÂF (-20 to +60 ÂC)
Storage Humidity: 20% to 90% RH, non-condensing
MTBF: 50000 hours
Dimensions (W x H x D): 4? x 1.25? x 3.25? (102mm x 32mm x 83mm)
