AMS Neve 88M
UPC/EAN #5060834530529
MPN #88M
10 in / 10 out USB audio interface with dual transformer-balanced 88RS preamps and mastering-grade AD/DA conversion
Legendary Sound for your Desktop
Designed and manufactured in England by Neve engineersm the Neve 88M dual mic preamp and USB audio interface brings the sound of iconic studios, such as Abbey Road, Air, and Capitol Studios, into your home studio setup. This robust front-end recording system uses the same transformer-balanced technology found in Neve's flagship large-format 88RS console. It is complemented with mastering-grade AD/DA conversion, producing world-class fidelity and premier studio musicality throughout.
Built to Last
Housed in a premium yet tough casing, the USB-powered 88M is the perfect recording solution for premium home studio environments and artists recording on location. As with all Neve equipment, sound quality takes ultimate priority, and the 88M is no exception. Premium analogue and digital components are utilised at every stage, ensuring maximum quality throughout the entire signal path.
Join the Elite
Serious artists can spend a small fortune on musical instruments and microphones, only to record them through low-quality audio interfaces; the 88M is designed to remedy this problem. Integrating the 88M audio interface into you home studio places you amongst an elite group of audio professionals.
Features
Dual microphone/line/instrument preamplifier powered by 88RS console technology10in/10out audio interfaceBig Neve iron - exclusive Marinair transformer balancedReference grade 24-bit/192kHz ESS ADC/DAC Chip SetHeavy duty Neve 88R monitor controlerIndependent high-headroom headphone amplifierADAT I/O - expandable digital connectivity for additional inputs and outputsBalanced Inserts - expandable connectivity to a host of outboard gearBuilt to last - rugged design featuring Neutrik connectors Neve console potsFutureproof - USB3.0 connectivityBus powered - ideal for recording on the movePlug & Play - class-compliant (Core Audio/ASIO)
Specifications
General Specifications
Headroom : +18dBu @ 1kHz (<0.5% THD+N)
Distortion (THD+N) : Typically 0.008% @ 1kHz (measured at +18dBu, 10Hz to 80kHz filter)
General Noise : <-85dBu (A-wtg)
Microphone Inputs
Frequency Response 20Hz to 20kHz : +/- 0.1dB
Frequency Response 10Hz to 35kHz : +/- 0.5dB
Dynamic Range : >110dB
Distortion (THD+N) : <0.004%
Noise EIN : -125dBA
Gain Range : +21dB to +68dB
Maximum Input Level (Max Gain @ 68dB) : -50dBu
Maximum Input Level (Min Gain @ 21dB) : -3dBu
Input Impedance : ?1.5k?
Line Inputs
Frequency Response 20Hz to 20kHz : +/- 0.1dB
Frequency Response 10Hz to 35kHz : +/- 0.5dB
Dynamic Range : >111dB
Distortion (THD+N) : <0.006%
Gain Range : -12dB to +35dB
Maximum Input Level (Max Gain @ 35dB) : -17dBu
Maximum Input Level (Min Gain @ -12dB) : +30dBu
Input Impedance : ?20k?18
DI Inputs
Frequency Response 20Hz to 20kHz : +/- 0.1dB
Frequency Response 10Hz to 35kHz : +/- 0.5dB
Dynamic Range : >100dB
Distortion (THD+N) : <0.006%
Gain Range : +13 to +60dB
Maximum Input Level (Max Gain @ 60dB) : -42dBu
Maximum Input Level (Min Gain @ 13dB) : +5dBu
Input Impedance : ?900k?
Insert Sends
Maximum Output Level : 18dBu (Balanced TRS)
Dynamic Range : >112dB
Mon Outputs
Maximum Output Level : 18dBu (Balanced TRS)
Dynamic Range : >113dB
Headphone output (150 Ohm load)
Maximum Output Level : 10dBu
Frequency Response : 20-20kHz +/- 0.3dB
Distortion (THD +N) : <0.007% @10dBu 1kHz
Noise floor : -96dBA
Metering
Signal : -43dBFS
Clip : -3dBFS
Crosstalk
Inter-channel crosstalk : <-60dBr @ 10kHz
Dimensions
Height : 76mm/3 inches
Width : 182mm/7.2 inches
Depth : 203mm/8 inches
Weight : 1.675Kg/3.7Lbs
Heat Dissipation : <5 watts
Power factor : N/A
Voltage : USB3
Current : <900mA
