Zoom MSH-6 Capsule
UPC/EAN #4515260013937
MPN #ZMSH6
Mid-side microphone capsule. For use with H5, H6, H8,Q8, U-44, F4, F8, F8n
MS ("Mid-Side") recording: an incredible technique that allows you to actually adjust the width of the stereo image after it has been recorded, making it especially useful for film, video and television projects.
Although the MSH-6 MS capsule appears to be just one microphone, it actually contains two mic elements, positioned directly on top of one another. One of the microphones inside the MSH-6 is unidirectional (that is, it is mostly sensitive to signal coming from directly in front, and less sensitive to signal coming from behind or from the sides) while the other is bi-directional (that is, it is mostly sensitive to signals coming from directly in front and directly behind, and less sensitive to signal coming from the sides).
The basic concept behind MS recording is that the Mid microphone picks up signal coming from the center, while the Side microphone creates ambience and directionality by adding or subtracting information from either side.
Inside the H6 MS capsule, the directional ("Mid") mic faces forwards while the bi-directional ("Side") mic is set perpendicular to it.
The Mid-Side technique works well whenever you need a variable amount of room sound. It can also be used for studio recording, and its convenience and flexibility make it a good option for rehearsal and live concert recording as well. Another benefit is that it provides total mono compatibility, making it an excellent choice for stereo recordings that may eventually be played back in mono, such as TV broadcasts.
Features
Mid-Side Recording: Captures detailed stereo sound with adjustable width for precise soundscapes.Modular Compatibility: Easily attaches to compatible Zoom recorders for flexible audio setups.Professional Sound Quality: Ideal for music, film, or field recordings.Compact Design: Lightweight and portable for easy use in any location.Creative Control: Allows post-recording adjustments to stereo width for perfect mixing.
Specifications
General Specifications
Interchangeable stereo microphone capsule for Zoom H5, H6, Q8, F1, and U-series devicesMid-side microphone design
Microphone Elements
Cardioid mid microphone for direct sound captureBi-directional side microphone for ambient sound capture
Polar Patterns
Adjustable stereo width control via mid-side decoding (raw MS or stereo file output)
Frequency Response
20 Hz " 20 kHz
Maximum Sound Pressure Level (SPL)
136 dB SPL
Connectivity
Proprietary Zoom 10-pin capsule connection
