UPC/EAN #4515260019977     MPN #ZH3VR

$329.99

Free shipping in Canada. Conditions

4 built-in mics arranged in an Ambisonic array, full-sphere surround sound recording



The H3-VR's 4-capsule Ambisonic mic captures 4 channels of 360-degree audio up to 24 bit/96 kHz. The onboard decoder automatically converts the raw Ambisonics A audio to VR-ready Ambisonics B audio, so it can easily be paired with your 360-video. And no computer is required.

The H3-VR can also record stereo files in binaural mode, providing a hyper-realistic spatial recording for 2D creators looking to add more depth to their sound. For musicians, this means transporting fans from the back row to center stage.

A 6-axis motion sensor provides the H3-VR with Auto Mic Position and Level Detection, so however you position the mic from scene to scene, your 360-audio and video orientations will stay aligned.

Creators can monitor their audio while recording and with the H3 Control App, creators can remotely access transport controls, levels and metadata notes right from their iOS device.

After audio is recorded, the onboard Ambisonics playback allows you to rotate the H3-VR to simulate spatial audio while listening.
  • 4 built-in mics arranged in an Ambisonic array
  • Full-sphere surround sound recording
  • Single-knob gain control of all input levels
  • Onboard Ambisonics A to B decoding
  • Three recording modes: Ambisonics, Stereo Binaural or Standard Stereo
  • Record up to 24bit/96kHz
  • Stereo binaural monitoring of Ambisonics signal
  • Headphone output and line output
  • Slate tone
  • Extensive metadata
  • Auto Mic Position Detection using 6-axis gyroscope (upfront, end fire,upside-down, end fire inverted)
  • Level Function to ensure precise angle placement
  • Wireless iOS remote control available through the BTA-1 Bluetooth adapter
  • Onboard Ambisonics playback with audio rotation
  • Accurate internal clock with .5ppm discrepancy
  • USB 2.0 Audio Interface Mode
  • Zoom Ambisonics Player software to play, change a direction, and convert to binaural, stereo,and 5.1ch surround file
  • Powered by 2 AA batteries (6-7 hours of operation) or USB bus power
  • Records to SD card up to 512GB
  • Recording Media
    Cards compatible with microSD/microSDHC/microSDXC specifications (Class 4 or higher)

    Recording formats
    Ambisonics A, Ambisonics B (FuMa/AmbiX)
  • WAV 4ch poly (supports BWF and iXML): 44.1 kHz/16-bit, 44.1 kHz/24-bit, 48 kHz/16-bit, 48 kHz/24-bit, 96 kHz/16-bit, 96 kHz/24-bit

  • Stereo
  • WAV stereo (supports BWF and iXML): 44.1 kHz/16-bit, 44.1 kHz/24-bit, 48kHz/16-bit, 48 kHz/24-bit, 96 kHz/16-bit, 96 kHz/24-bit

  • Binaural
  • WAV stereo (supports BWF and iXML): 44.1 kHz/16-bit, 44.1 kHz/24-bit, 48kHz/16-bit, 48 kHz/24-bit

  • Display
  • 1.25" monochrome LCD (96x64)

  • Motion sensor
  • 6 axes (3-axis gyro, 3-axis acceleration)

  • Built-in Ambisonic mic
  • 4 matched unidirectional condenser mics
  • Maximum sound pressure input: 120 dB SPL
  • Mic gain: +18 - +48 dB

  • LINE OUT
  • Connector: 3.5 mm stereo mini
  • Maximum output level: 10 dBu (1 kHz, 10 k load)

  • PHONE OUT
  • Connector: 3.5 mm stereo mini
  • Maximum output level: 20 mW + 20 mW (into 32 load)

  • USB
  • Connector: microUSB

  • Mass storage operation
  • USB 2.0 High Speed

  • Audio interface operation
  • 2 in/2 out (stereo/binaural input), USB 2.0 Full Speed
  • 44.1 kHz/16-bit, 48 kHz/16-bit
  • 4 in/2 out ( Ambisonics A/FuMa/AmbiX input), USB 2.0 High Speed
  • 44.1 kHz/24-bit, 48 kHz/24-bit

  • Power
  • 2 AA batteries (alkaline, rechargeable NiMH or lithium)
  • AC adapter (ZOOM AD-17): DC 5V/1A (supports USB bus power)

  • Estimated continuous recording time using batteries
    48 kHz/24-bit, FuMa Rec Mode
  • Alkaline batteries: about 11.5 hours
  • NiMH batteries (1900 mAh): about 11.5 hours
  • Lithium batteries: about 24 hours

  • External dimensions
  • 76 mm (W) x 78 mm (D) x 123 mm (H)

  • Weight (main unit only)
  • 120 g
  • 3.0
    John
    Winnipeg, MB
    June 5, 2020
    Works as it should, but lacks a few essentials.
    This is a handy little unit that works fine, but needlessly lacks a few necessary items.

    It is very small and light. It seems quite delicate for field use. You wouldn't want to drop it. The buttons are made from a very light plastic, so I hope it holds up over time. Read more
