Zaxcom VRX1
MPN #VRX1
The Zaxcom VRX1 is a portable belt-worn analog VHF IFB audio receiver built to monitor audio and cue
talent in the film, television, and broadcast industries. Simply connect an earpiece or headphones to the 3.5mm output for clean, reliable audio performance.
VRX1 utilizes an innovative direct conversion design that is capable of turning into and decoding 10 analog
broadcast channels in the VHF 192-217 MHz frequency range.
Among its core features is an intuitive voice prompt system, voting, frame specific audio delay, an adaptive
squelch, headphone equalization, and multiple power options all in a rugged, easy to use device.
Technology
As an analog VHF receiver with frequency modulation (FM), VRX1 features an innovative direct conversion
design to receive audio. Zaxcom has refined this technology to reduce all forms of RF interference while
extending battery life.
Connectivity
VRX1 operates in the VHF 192-217 MHz frequency range and is pre-programmed with 10 standard channels for quick setup. The preset channels are: 216.025, 216.075, 216.175, 216.275, 216.425, 216.525, 216.725, 216.825, 216.925, and 216.975.
Users can select one of the 10 channels using the front two push buttons, both of which are programmable.
When enabled, a voice prompt system allows for users to select channels as well. Pre-programmed
channels can be reconfigured through the optional Zaxcom GUI Bridge (ZGB).
? VRX1 is also available in the 76-86 MHz frequency range as a special order.
Batteries & Charging
VRX1 is designed to support alkaline, rechargeable Ni-MH, and lithium batteries. Two AA batteries are needed to power the unit.
Specifications
VRX1 measures 2.46"x 4.60"x 0.640" with a weight of 4 ounces with two NiMH batteries.?
Compatibility
VRX1 is compatible with analog VHF FM Comtek transmitters operating on 192-217 MHz. This allows you to
mix and match VRX1 with other Comtek IFB receivers connected to the same transmitter. Future
compatibility with other manufacturers will be determined.
Current transmitter compatibility:
Comtek BST 75-216Comtek BST 25-216Comtek M-216
