Universal Audio Volt 876
MPN #UA-VOLT876
$1379.00
Save 19.8%, MSRP $1719.00
24-in 28-out USB, Eight vintage preamps, analog compressors, 32-bit conversion, ADAT expandability, mobile-ready, LUNA and UAD plug-in suite included
Bring legendary analog warmth and professional-grade power to your studio with the Volt 876 USB Recording Studio, a 24-in/28-out audio interface built for music producers who demand rich sound and advanced workflow. Designed by the makers of Apollo interfaces, the Volt 876 combines eight Vintage mic preamps and UA's classic 1176-style analog compressors with pristine 32-bit / 192 kHz conversion, letting every vocal, instrument, and mix shine with studio-level clarity and character. Whether you're tracking a full band or layering complex sessions, its front-panel controls and assistive features like auto-gain and full session recall make capturing great takes faster and easier.
With seamless integration into Universal Audio's ecosystem, the Volt 876 offers a smooth, intuitive recording experience across Mac, PC, iPad, and iPhone. Pair it with UA's LUNA DAW to unlock smart AI-powered tools like voice control, tempo detection, and unlimited tracks " or dive into your production toolkit with a premium suite of UAD plug-ins, including iconic compressors, EQs, amps, and virtual instruments. Expand your setup via ADAT, monitor with low-latency cue mixes, or record on the go with iOS compatibility. Whether you're producing in the studio or on the move, Volt 876 is built to inspire.
Features
Analog Sound for Every Channel: Includes eight Vintage mic preamps and analog compressors modeled after classic studio gear.Studio-Quality Audio: Delivers high-resolution 32-bit recording for clear, detailed sound on all your devices.Smart Recording Tools: Works with LUNA DAW to offer features like Voice Control, Instrument Detection, and automatic tempo sync.Instant Setup and Recall: UAD Console app lets you save, recall, and manage session settings with ease.Powerful Plug-In Suite: Comes with premium UAD plug-ins, like the LA-2A compressor, Pultec EQs, and guitar amp models.Expandable System: Connect up to three Volt 876 units or integrate with other ADAT gear for more channels.Record Anywhere: Compatible with Mac, PC, iPhone, and iPad for mobile and desktop recording.Low-Latency Monitoring: Offers real-time monitoring with talkback and two stereo cue mixes for live feedback.Built for Collaboration: Includes two studio-grade headphone amps and easy front-panel controls.Ready for Instruments and Mics: Features Hi-Z inputs, 48V phantom power, and all the I/O you need for a full studio setup.
Specifications
General Specifications
24-in / 28-out USB 2.0 audio interface32-bit / 192 kilohertz audio conversionEight analog microphone preamps with Vintage mode (UA 610 tube emulation)Eight onboard 76 Compressors (1176-style analog compression)Digitally controlled gain with 60 decibels of rangeFull session recall via UAD Console app and LUNA DAWTwo low-latency stereo cue mixes with talkbackBuilt-in talkback microphoneRealtime direct monitoring with dedicated front panel controlsCompatible with Mac, Windows, iPhone, and iPadStandalone ADAT mode supportedClass-compliant for macOS and iOSWDM driver required for Windows via UA ConnectStylish, rugged 1U rackmountable chassis with rack ears and rubber feet
Analog Inputs
Microphone Inputs Frequency Response: 20 Hertz to 20 kilohertz, ±0.1 decibelsMicrophone Inputs Dynamic Range (A-weighted): 116 decibelsMicrophone Inputs THD + Noise: -110 decibels (0.0003 percent)Microphone Inputs Maximum Input Level: 14 dBuMicrophone Inputs Input Impedance: 2 KilohmsMicrophone Inputs Gain Range: 60 decibelsMicrophone Inputs Phantom Power: +48 volts (switchable)Microphone Inputs Connector Type: XLR Female (pin 2 positive)Instrument Inputs Frequency Response: 20 Hertz to 20 kilohertz, ±0.04 decibelsInstrument Inputs Dynamic Range (A-weighted): 116 decibelsInstrument Inputs THD + Noise: -87 decibels (0.004 percent)Instrument Inputs Maximum Input Level: 12.5 dBuInstrument Inputs Input Impedance: 1 MegohmInstrument Inputs Gain Range: 60 decibelsInstrument Inputs Connector Type: Quarter-inch TS unbalancedLine Inputs Frequency Response: 20 Hertz to 20 kilohertz, ±0.05 decibelsLine Inputs Dynamic Range (A-weighted): 116 decibelsLine Inputs THD + Noise: -108 decibels (0.0004 percent)Line Inputs Maximum Input Level: 22 dBuLine Inputs Input Impedance: 10 KilohmsLine Inputs Gain Range: 60 decibelsLine Inputs Connector Type: Quarter-inch TRS balanced or TS unbalanced
Analog Outputs
Line Outputs Frequency Response: 20 Hertz to 20 kilohertz, ±0.1 decibelsLine Outputs Dynamic Range (A-weighted): 119 decibelsLine Outputs THD + Noise: -111 decibels (0.0003 percent)Line Outputs Maximum Output Level: 20.2 dBuLine Outputs Output Impedance: 100 OhmsLine Outputs Connector Type: Quarter-inch TRS balanced or TS unbalancedHeadphone Outputs Frequency Response: 20 Hertz to 20 kilohertz, ±0.2 decibelsHeadphone Outputs Dynamic Range (A-weighted): 116 decibelsHeadphone Outputs THD + Noise: -108 decibels (0.0004 percent)Headphone Outputs Maximum Output Power into 32 Ohms: 225 milliwattsHeadphone Outputs Maximum Output Power into 600 Ohms: 35 milliwattsHeadphone Outputs Connector Type: Quarter-inch TRS stereo unbalanced
Digital I/O
USB Port: One USB 2.0 Type-CMIDI Ports: In and Out (two 5-pin DIN connectors)ADAT Optical Inputs: Two (S/MUX capable)ADAT Optical Outputs: Two (S/MUX capable)ADAT Channel Count at 44.1 to 48 kilohertz: 16 channelsADAT Channel Count at 88.2 to 96 kilohertz: 8 channelsADAT Channel Count at 176.4 to 192 kilohertz: 4 channelsS/PDIF via Toslink: Stereo at all supported sample rates
A/D " D/A Conversion
Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192 kilohertzBit Depth: 32-bit
Software Included (Universal Audio)
LUNA Digital Audio WorkstationTeletronix LA-2A Tube CompressorUA 1176 Classic FET CompressorPultec Passive EQ CollectionCentury Tube Channel StripOxide Tape RecorderVerve Analog Machines EssentialsPure Plate ReverbGalaxy Tape EchoPolyMAX SynthShowtime '64 Tube Guitar Amp
Third-Party Software Included
Ableton Live LiteMelodyne Essential by CelemonyAmpeg SVT-VR Classic Bass Bundle by Plugin AllianceMarshall Plexi Classic Amp Bundle by SoftubeVirtual Drummer DEEP by UJAMVirtual Bassist DANDY by UJAMLABS by Spitfire Audio
System Requirements
macOS Compatibility: Big Sur 11 or newerWindows Compatibility: Windows 10 64-bit or newerProcessor Compatibility: Intel, AMD, or Apple siliconUSB Requirement: USB 2.0 or higher portInternet Connection Required for software downloadsiOS Compatibility: iPadOS / iOS 16 or neweriOS Connection Requirements: USB-C or Lightning-to-USB camera adapter with external power to Volt 876
