Trinnov Audio MC12 Processor
MPN #MC12
Multichannel monitoring optimizer with 12-channel optimizer license for up to 7.1.6 surround sound systems, upgradable to 16-channel, and analog I/O via DB25
Multichannel Processors 12-channel Optimizer for a wide range of surround sound and immersive audio applications including post-production, broadcast and music monitoring. The MC12 meets requirements of surround sound systems to handle up to 7.1.4 immersive monitoring systems.
Customizable Profiles
Trinnov combines automatic processes with flexible fine-tuning tools that allow the sound system designer and the engineer to reach the best results while making the whole process easier and faster. 8 Customizable Profiles allow mixing different parameters independently of the 29 existing user presets.
Precise Monitoring
Monitoring relies on both consistent measuring and the best possible listening conditions. The industry is guided by many monitoring standards such as SMPTE / ITU / AES for sound systems, and that?s where Trinnov brings a new level of expertise.
A unique way to align crossovers
Individual driver and system measurements are acquired and analyzed, including the impulse response, delays, and gains. Trinnov?s unique crossover calibration engine computes the ideal filters, finding the best compromise to improve flatness, directivity, and attack in the overlapping frequency region.
Comprehensive Processing
Comprehensive 64-bit floating-point processing tools are included on each processor platform: routing and mixing matrixes, manual FIR filters, parametric EQs, graphic EQs, gains, trims, peak and RMS meters, manual delays, bass management, 4-way active crossovers, inputs formats, noise generators, polarity control, editable Submix matrixes, monitor controller, dynamic range controller.
DOLBY'S SYSTEMS INTEGRATION VIA DANTE
For Dolby Atmos Mixing rooms, the MC Dante can be easily integrated. The MC Pro Dante can meet the requirements of Dolby Atmos Home studios up to 9.1.6 speaker configuration whilst the MC-HCC is suitable for Dolby Atmos theatrical systems with up to 64 speakers. Soft keys allow you to add more control (bypass, bass management, presets & profiles selection...)
Audio signal goes from Protools to the RMU via the MTRX, gets back to the MTRX and is routed to the MC as an insert, then goes to the loudspeakers using MTRX DA converters.
MADE FOR AVID EUCON
The Trinnov App acts as a gateway between EUCON and Trinnov protocols, letting you control all parameters of your processor from your AVID control surface. Any EUCON enabled product is compatible.
The MC-Pro offers extensive EUCON compatibility and full integration with AVID control surfaces: S6, S5, S3, Dock as well as Icon D-Command & D-Control.
THE TRINNOV APP
Simply called Trinnov App this new free application for all our users will become a staple in your dock and facilitates set-up and use of all Trinnov processors.
This new macOS App lets you discover all Trinnov machines currently on your network. From it, you can execute basic essential functions from saving and loading presets to control volume or dim and mute. As well no more need of VNC you can now directly launch the web application of your machine(s) to perform a new set-up or calibration.
Features
16x AES/EBU i/o via DB2512x balanced in via DB2512x balanced out via DB25 and/or 8x XLRIncludes 12-channel Optimizer License
Specifications
DIGITAL AUDIO CONNECTIVITY
AES3 Inputs (DB25):Up to 16
AES3 Outputs (DB25):Up to 16
Wordclock (BNC):x1 Input, x1 Output
ANALOGUE AUDIO CONNECTIVITY
Balanced inputs (DB25):Up to 16
Balanced outputs (DB25):Up to 16
Balanced outputs (XLR):x8
AUDIO PROCESSING
Per channel:31 band EQ, FIR EQ, gain, polarity and delay
Per channel delay setting:Meters / Milliseconds / Frames
Global delay setting:Meters / Milliseconds / Frames
AUDIO PERFORMANCE
ADC Resolution / Sampling Rate:24 Bits/96Khz
DAC Resolution / Sampling Rate:24 Bits/192Khz
A/D Signal-To-Noise Ratio:119 dB (A-Weighted)
D/A Signal-To-Noise Ratio:118 Db (A-Weighted)
Reference Level:+18dBu @ 0dBfs (Balanced)
Processing Sampling Rate:Native, up to 192kHz
Processing Resolution:64 bits floating point
Clock / Jitter:attenuation > 50 dB Above 100Hz
POWER SUPPLY
Power requirement:240V / 110V - 50 / 60Hz (Manual Switch)
Power consumption:90W
Mains fuse:1A slow blow
Analogue section PSU:Dedicated linear PSU with toroidal transformer
Digital section PSU:Switch-mode PSU
WEIGHT & DIMENSIONS
Dimensions (W x H x D) mm:444 x 89 x 405
Dimensions (W x H x D) inches:17 1/2" x 3 1/2" x 16"
Shipping box dimensions (W x H x D) cm:68 x 56 x 21
Weight:9kg
Shipping weight / volume:12.60kg / 0.08 M3
Installation en rack:2U - Fixed Rack Ears
