Tentacle Sync TIMEBAR - Timecode Slate
UPC/EAN #4260452430121
MPN #TB1-SL
Lightweight kit with a precision-engineered acrylic board, durable clapper sticks and custom holder ensures versatile compatibility and flexibility for timecode display use
The TIMEBAR Timecode Slate is our all-in-one digital timecode slate kit, designed for seamless integration with the entire Tentacle Sync ecosystem. We?ve collaborated with premium slate maker Filmsticks to create this unique, versatile solution. The kit includes the TIMEBAR " our multipurpose timecode display " paired with a high-quality board, clapper sticks and a custom holder, that also serves as a mount for the TIMEBAR. This lightweight, yet robust, setup not only enhances portability but offers flexibility on set. The TIMEBAR can be swiftly attached or detached from the slate, functioning independently as a timer, message display
or stopwatch, whether mounted or not, all controlled effortlessly via our Setup App.
The OLED display not only provides high contrast, but also ensures low energy consumption, allowing the TIMEBAR to last throughout the entire day.
Additionally, the slate is built for longevity, with every component being user-replaceable.
Even the long-lasting built-in lithium battery can be easily swapped by users after years of use,
ensuring continued reliability. The TIMEBAR Timecode Slate is the ultimate tool for precise timecode management and efficient production workflows.
Features
Precision-engineered Acrylic BoardDurable Clapper SticksCustom-designed TIMEBAR Holder / MountHigh-contrast OLED Technology with a Wide Viewing Angle Typical Battery Runtime 24 hoursControl, Sync Operate all devices via Bluetooth Timecode Generator with TC In & OutTimer & Stopwatch FunctionalityText DisplayTentacle Sync Studio Software License included (macOS) Two Year Limited WarrantyTIMEBAR Designed and Manufactured in Germany
Specifications
CONNECTIVITY
Timecode In/Out: 3.5 mm Jack USB Connection: USB-C (USB 2.0)
USB Operating Modes: Charging, Firmware Update
CONTROL & SYNC
Bluetooth: 5.2 Low Energy
Remote Control: Tentacle Setup App (iOS /Android)
Synchronization: Via Bluetooth (Tentacle Setup App)
Jam-Sync via Cable
Timecode In / Out: LTC via 3.5 mm Jack
Drift: High Precision TCXO: Accuracy less than 1 Frame Drift in 24 Hours (-30 to +85 C)
Frame Rates: SMPTE 12M / 23.98, 24, 25 (50), 29.97 (59.94), 29.97DF, 30 (60)
POWER
Power Source: Built-in rechargeable Lithium Polymer Battery
Battery Capacity: 2200 mAh
Battery Operation Time in Slate Mode: Minimum 2 weeks
Battery Operation Time Continuous Mode: Approx. 6 (highest brightness) to 80 hours (lowest brightness)
Battery Charging Time: Max. Standard 4"5 hours, Fast Charge 2 hours
HARDWARE
Weight: 786 g / 27.7 oz (incl. battery) Dimensions: 280 - 226 - 43 mm / 11 - 8.9 - 1.7 in
WHAT'S IN THE BOX:
1 - TIMEBAR " Multipurpose Timecode Display 1 - Acrylic Board (280 - 190 - 5 mm / 11 ??)
1 - Clapper Sticks
1 - TIMEBAR Holder/Mount
1 - USB-A to USB-C Cable
1 - Zipper Bag Long
1 - Software License for Tentacle Sync Studio (macOS) 2 x M4 Screws
1 - 1.5 Hex Key
