Telefunken M80-WH
UPC/EAN #899051002152
MPN #SYTM-023
$347.00
Save 13.3%, MSRP $400.00
Wireless capsule head variant of the M80 Dynamic. Black body and chrome grid.
The wireless capsule is sonically identical to the M80 standard and M80-SH and has the same condenser like performance, minimal proximity effect, and superior feedback rejection one expects in its sibling products.
The product features the same exact dynamic capsule, head grille, and output transformer all neatly packed within a capsule body that is ready to be mated to your wireless transmitter system of choice.
COMPATIBLE with the following transmitters:
Shure:
. Axient
. UHF-R
. QLXD
. ULXD
. ULX
. PG
. PGX
Lectrosonics:
. HH
. HHa
Sony:
. UTX-M03
NOT COMPATIBLE with the following transmitters:
Shure:
. BLX
. GLXD
. PGXD
The TELEFUNKEN Elektroakustik M80 Dynamic microphone has rapidly become a new standard for live performance and stage use. The microphone features a low-mass capsule built with a super thin Mylar membrane that is coupled with our propriety step-up transformer to give superior clarity and extended high frequency response (which in many ways is similar to what one might expect from a condenser microphone), in a rugged design meant for daily abuse in touring applications.
In 2008 a band called Green Day tried the M80 and found they liked the tone of the microphone in various applications, but especially on vocals. The only fly in the ointment was that Green Day isn't a club band, they're an internationally prominent act that regularly sells out arena and stadium venues, which in this day and age means that a wired vocal microphone is out of the question.
After a bunch of experimentation and some custom machining the design team at TELEFUNKEN Elektroakustik was able to successfully modify Green Day's current Shure wireless mics to feature an M-80 wireless head, complete with TELEFUNKEN Elektroakustik headgrill, capsule, and output transformer.
After giving the modified Shure mics a try, more than 40 wireless modifications were ordered by Green Day as they embarked on a world tour. From this success "team TELEFUNKEN" developed a standard modification process for Shure microphones (which made the guys at Shure a little angry with us!!).
This is an entire M-80 (capsule, head grill, output transformer), neatly packed in a much shorter body with the screw on terminal connections. The result is a whole lot of microphone crammed in a little tiny space that provides 10 pounds of sound in a 6 oz package.
M80-WH for Shure brand wireless transmitters
M80-WH6 for Line6 brand wireless transmitters
Specifications
Color : Chrome grid.Type : Dynamic Moving CoilCapsule : 25mmFrequency Range : 30Hz / 18kHzPolar Pattern : Super-cardiodSensitivity : 1.4mV/PaOutput Impedance : 300 ohmsMaximum SPL : > 140dBNon Linear Distortion : Less than or equal to 0.5% at 100 dyne / cm sqSelf Noise :Tube Type : 6072a General Electric JAN twin triodePower Type :Size : 3.33" (85mm) length x 2.5" (63mm) diameterWeight : 6oz (168g)Supplied Accessories : Cardboard carrying case
