Tascam Series 8p Dyna
UPC/EAN #043774034178
MPN #SERIES-8P-DYNA
$1279.00
Économisez 19.6%, Prix suggéré $1590.00
8 HDIA mic preamps, onboard analog compressors, dual S/MUX optical outs, ADAT compatible, +48V phantom, word clock I/O, TRS & D-Sub outputs, rackmount design.
Designed for serious studio work and stage applications, the TASCAM SERIES 8p Dyna offers a powerful, all-in-one mic preamp and digital audio conversion solution. It features eight of TASCAM's top-tier HDIA (High Definition Instrumentation Architecture) mic preamps, delivering outstanding clarity, ultra-low noise, and impressive dynamic range. Each input channel also includes an analog compressor with single-knob control and true bypass, making it easy to dial in the right sound for any recording situation. The rugged 1U rack-mountable unit also supports phantom power on all channels and provides both TRS and D-Sub analog outputs for flexible routing.
Thanks to dual S/MUX optical outputs, the SERIES 8p Dyna integrates effortlessly into existing setups as a high-quality front end for any S/MUX- or ADAT-compatible audio interface, including TASCAM's SERIES 102i and 208i. With support for sample rates up to 192kHz, precision word clock sync, and detailed front-panel level metering, the SERIES 8p Dyna ensures professional-grade performance in every application. Whether expanding your recording rig or building a compact, capable standalone system, this unit brings TASCAM's renowned reliability and sound quality to any setup.
Caractéristiques
8 Premium Mic Preamps: Delivers clean, low-noise performance with TASCAM HDIA preamps.Built-in Analog Compressors: Each channel includes a single-knob compressor with true bypass.Flexible Input Options: Combo inputs for mics, instruments, or line-level gear-2 on front, 6 on back.Phantom Power per Channel: Individually switchable +48V phantom power for each mic input.Optical Expansion Ready: Dual S/MUX optical outputs for up to 8 channels at 96kHz or 4 channels at 192kHz.Versatile Analog Outputs: Outputs on both TRS jacks and D-Sub connector for broad compatibility.Perfect Interface Expander: Ideal companion for SERIES 102i, SERIES 208i, or other ADAT/S/MUX-equipped devices.Stand-Alone Operation: Functions independently as a high-quality front end for studio or live use.Rugged 1U Rackmount Design: Built to withstand professional environments with durable metal construction.Visual Monitoring: LED meters show input levels, compression, and peak status at a glance.
Spécifications
General Specifications
8 channel mic preamp and DA converterBuilt-in analog compressor with true bypassDual S MUX optical outputs (ADAT compatible)Word clock in and out with In Out Thru switch1U rack mount metal enclosureSuitable for expansion or stand-alone front end
Audio Inputs
8 TASCAM HDIA mic preampsFront panel 2 combo XLR TRS mic instrument inputsRear panel 6 balanced mic line inputsInput impedance mic 2.3k ohmsInput impedance instrument 1M ohms or moreInput impedance line 10k ohmsGain range 52 dBIndividually switchable 48V phantom power
Audio Outputs
8 TRS balanced line outputs25-pin D-Sub balanced output connectorOutput impedance 200 ohms or lessNominal output level plus 4 dBuMax output level plus 20 dBu
Digital Audio Output
Dual optical output JEITA RC-5720CSupports S MUX2 at 88.2kHz 96kHzSupports S MUX4 at 176.4kHz 192kHz
Word Clock I O
Word clock input via BNC 2.0 to 5.0 VppWord clock output via BNC 2.0 VppInput and output impedance 75 ohms
Audio Performance
Mic amp EIN -127 dBu or lowerFrequency response 20 Hz to 80 kHz plus or minus 5 dBTHD mic line to line out 0.0007 percentTHD instrument to line out 0.0009 percentTHD to digital output 0.001 percentSNR up to 116 dBCrosstalk mic to line out 119 dBCrosstalk mic to digital output 114 dB
Power and Dimensions
Power DC 12V via included PS-P1230 adapterPower consumption 16 WDimensions 482 x 44.8 x 228.8 mmWeight 2.6 kg
Included Items
Main unitAC adapter PS-P1230 with 3 plug typesRackmount screw kitOwner's Manual with warrantyTASCAM ID registration guide
