Tascam Series 102I
UPC/EAN #043774034000
MPN #SERIES-102I
$449.00
Économisez 19.8%, Prix suggéré $560.00
10 in 2 out USB interface, Ultra HDDA mic preamps, optical S/MUX input, 24bit 192kHz, dual headphone outs, built-in DSP effects, MIDI I O, Cubase LE included.
The TASCAM SERIES 102i is a powerful and compact audio/MIDI interface designed for musicians, producers, and content creators seeking professional-quality recording capabilities. Featuring two of TASCAM's Ultra HDDA mic preamps and support for 24-bit/192kHz audio, it ensures transparent sound with ultra-low noise. With dual combo XLR/TRS inputs, MIDI I/O, and an optical S/MUX input for expanding up to 10 total inputs, this interface is ideal for capturing everything from vocals to full drum kits. Built-in DSP offers zero-latency monitoring with reverb, EQ, and compression, while dual headphone outputs allow for flexible monitoring setups.
Designed with ease of use in mind, the SERIES 102i sports an angled tabletop layout with a large monitor knob and quick-access controls. The bundled TASCAM Control software enables deep routing and mixing customization, and compatibility with iOS, macOS, and Windows ensures broad flexibility. Included software from Steinberg, IK Multimedia, and iZotope makes it a complete production package out of the box, perfect for mobile and studio recording alike.
Caractéristiques
Professional Audio Quality: Captures sound at up to 24-bit/192 kHz with ultra-low noise mic preamps.Versatile Inputs and Outputs: 2 mic/line/instrument inputs and an optical input for up to 8 additional channels.Dual Headphone Outputs: Two powerful headphone amps for separate monitoring needs.Built-In DSP Effects: Includes reverb, EQ, compression, and more for latency-free processing.Flexible Routing and Mixing: Free software lets you assign any input to any output with full mixer control.Quick Access Controls: Large front-panel knobs and angled design for easy adjustment during sessions.Expandable for Growth: Optical S/MUX input adds channels as your needs increase.Included Production Software: Bundled with Cubase LE, AmpliTube, Neutron Elements, and T-RackS.Mobile and Desktop Friendly: Works with Windows, macOS, and iOS devices.Solid and Portable Design: Compact and durable, with external power supply and USB connectivity.
Spécifications
General Specifications
USB audio MIDI interface with 10 inputs and 2 outputs24-bit 192kHz resolutionTASCAM Ultra HDDA mic preampsInternal DSP mixer with reverb compressor and 4-band EQExpandable input via optical S/MUX up to 8 channelsFree TASCAM Control software for routing and DSP controlCompatible with Windows macOS and iOSDual headphone outputsAngled tabletop design
Audio Inputs
2 XLR TRS combo mic line instrument inputsMic input impedance 1.5k ohmsMic input gain range 58 dBInstrument input impedance 1M ohms or moreLine input impedance 10k ohmsOptical input S MUX via JEITA RC-5720C
Audio Outputs
2 TRS line outputs balancedLine output nominal level plus 4 dBuLine output max level plus 20 dBuHeadphone output max power 18 mW into 32 ohmsHeadphone output impedance 83 ohmsWorking impedance 16 to 300 ohms
Audio Performance
EIN -129 dBu or lowerFrequency response 20 Hz to 20 kHz plus 0 minus 0.4 dB at 44.1k 48kHzFrequency response 20 Hz to 40 kHz plus 0 minus 0.8 dB at 88.2k 96kHzTHD mic in 0.0016 percentTHD line in 0.0023 percentSNR 109 dB or higherCrosstalk 100 dB or higher
Connectivity
USB 2.0 High Speed (480 Mbps)MIDI IN and OUT via 5-pin DIN4-pin USB B type connector
Power and Dimensions
Power supply DC 12V via included PS-P1220E adapterPower consumption 7.2 WDimensions 186 x 65 x 160 mmWeight 1.1 kgOperating temperature 5 to 35 degree C
Computer Requirements
Windows with USB 2.0 or 3.0 dual core 2 GHz CPU 2GB RAMmacOS with USB 2.0 or 3.0 dual core 2 GHz CPU 2GB RAMiOS with Core Audio support
Included Items
Series 102i unitAC adapter PS-P1220E with 3 plug typesUSB cableDAW software installation guidesDAW plugin software installation guidesOwner's Manual with warranty
