Tascam MX-8A
UPC/EAN #043774033645
MPN #MX-8A
$1989.00
Save 20.4%, MSRP $2500.00
MX8A 8x8 matrix mixer with DSP, USB audio, mic/line Euroblock I/O, 50 scene presets, ANC, ducking, app control, RS232 RS485 Ethernet, 1U rackmount, 21W power
The TASCAM MX-8A is a versatile 8-input, 8-output matrix mixer designed for professional audio installations in environments like restaurants, conference rooms, and retail spaces. With built-in DSP processing and a compact 1U rackmount design, it offers precise control over signal routing, mixing, and optimization across multiple zones. The MX-8A supports both mic and line level inputs with phantom power, and includes a USB audio interface for seamless integration with computers and mobile devices.
Tailored for flexible system setups, the MX-8A comes equipped with advanced features such as scene presets, ducking, ambient noise compensation, and full control via dedicated software for both integrators and end-users. With network and serial connectivity options, plus compatibility with wall-mounted controllers, this mixer delivers reliable, high-quality performance for any installed audio system.
Features
8 Mic/Line Inputs + 8 Line Outputs: Supports a variety of audio sources with phantom power and Euroblock connectors.Built-in DSP Processing: Offers EQ, compression, ducking, auto level control, delay, limiter, and more for input/output optimization.10x10 Matrix Mixer: Route and mix any input to any output zone with full flexibility, including USB audio paths.Custom Scene Presets: Save and recall up to 50 configurations with tailored DSP and routing settings.Remote Control Ready: Compatible with MX CONNECT (integrators) and EZ CONNECT (end users) for complete system management.USB Audio Interface: Functions as a 2-in/2-out USB audio interface for playback or recording on Windows, macOS, iOS, or Android.Clear Audio in Real-Time: Features ducking and ambient noise compensation for automatic volume clarity in dynamic environments.Wall Controller Compatibility: Connect up to 8 RC-W100 wall controllers for hands-on control of volume and source selection.Versatile External Control Options: Supports Ethernet, RS-232C, and RS-485 for integration with control systems.1U Rackmount Design: Fits easily into standard AV installations and includes all mounting accessories.
Specifications
General Specifications
Matrix mixer with integrated DSP8 mic line inputs with phantom power support8 line outputsUSB 2.0 audio interface with 2 in 2 out channelsCompatible with Windows macOS Android iOS1U rack mountable designPower consumption 21WDimensions 483 x 45 x 304.1 mmWeight 3.0 kg
Audio Inputs
Connectors Euroblock Balanced 3.81 mm pitchMic input max level plus 26 dBuLine input max level plus 24 dBuMinimum input level minus 77.5 dBuInput impedance 2.2 kiloohms or higher
Audio Outputs
Connectors Euroblock Balanced 3.81 mm pitchNominal output level plus 4 dBu or plus 6 dBu depending on reference levelMax output level selectable from plus 15 dBu to plus 24 dBuOutput impedance 200 ohms or lower
DSP Processing Input Modules
Mic line switchingPhantom power on offPad mic inputMic gainCompressor4 band EQ2 band parametric EQLow shelving EQ or high pass filterHigh shelving EQAuto level controlMuteFaderFader and mute grouping
DSP Processing Matrix Mixer
10 by 10 matrixMuteFaderFader and mute groupingDuckingAmbient noise compensator
DSP Processing Output Modules
10 band EQ8 band parametric EQLow shelving EQ or high pass filterHigh shelving EQ or low pass filterDelayLimiterPhase switchingTest toneMuteFaderFader and mute grouping
Audio Performance
EIN minus 126 dBu or less with 150 ohm inputFrequency response 20 Hz to 20 kHz plus or minus 0.5 dBTHD plus N 0.005 percent or lessSignal to noise ratio 106 dB or higherCrosstalk 106 dB or higherDynamic range 106 dB or higher
Connectivity and Control
RS 232C D sub 9 pin femaleRS 485 RJ 45Ethernet RJ 45 TCP IP 100BASE TXSupports up to 8 daisy chained RC W100 wall controllers
Software Compatibility
TASCAM MX CONNECT for integratorsTASCAM EZ CONNECT for end users
Supported Audio Drivers
Windows UAC 2.0 WDMmacOS iOS UAC 2.0Android UAC 2.0
Included Items
Main unitPower cord16 Euroblock plugsCable band kitRackmount screw kitOwners manual with warranty
