SPL Pre One
UPC/EAN #4260149322456
MPN #1907
Dual-channel mic preamp with discrete design, 48V phantom power, Hi-Z instrument input, gain range +8 to +62 dB, high-pass filter, phase reverse, Flair and Contour EQ features
The SPL Pre One is a high-performance dual-channel microphone preamplifier designed to deliver outstanding sound quality through its discrete technology. Ideal for both professional audio recording and live performances, the Pre One is equipped with two preamplifiers that ensure an open and transparent sound, perfect for capturing the nuances of both vocals and instruments. One of its standout features is the inclusion of a Hi-Z instrument input, allowing instruments like electric guitars to benefit from the high-quality preamp sound, making it versatile for a variety of recording setups.
Both preamps come with adjustable gain control ranging from +8 to +62 dB, making it compatible with demanding microphones. Each channel also features 48V phantom power, a high-pass filter to eliminate low-frequency noise, and phase reverse functionality for greater sound control. The Pre One also offers unique EQ settings with the Flair and Contour functions, enhancing the high frequencies for a silky sound or creating a more compact mix. With its high-quality Neutrik XLR mic inputs and separate line outputs, this preamplifier is a professional-grade addition to any recording setup.
Features
Dual-channel microphone preamplifiersHi-Z instrument input for electric instrumentsGain control for adjusting preamplification48V phantom power for condenser microphonesHigh-pass filter to reduce low-frequency noisePhase reverse function for signal polarityFlair and Contour EQ presets for enhanced soundPAD function to handle high-level signalsSeparate line outputs for each preampBuilt with high-quality components in GermanyExternal power supply with internal regulation for optimal performance
Specifications
General
Product type: Dual-channel microphone preamplifierTechnology: DiscreteSeries: Series One
Preamplifiers
Number of channels: 2Gain control: +8 dB to +62 dBPhantom power: +48 V (independent for each channel)High-pass filter: 6 dB/octave, 80 HzPhase reverse: 180 phase inversionPAD switch: -20 dB (rear DIP switches)Flair: Enhances high frequencies for silky highsContour: Smooths the mix while maintaining presence
Inputs
Mic inputs: 2x Neutrik XLR (balanced, gold-plated contacts)Hi-Z instrument input: 1 (on preamplifier 2, disables mic input 2 when used)Input impedance (Mic): 10 k?Input impedance (Line): 1.1 M?Maximum input gain (Mic, +8 dB Gain): +13.5 dBuMaximum input gain (Inst, -6 dB Gain): +23.5 dBu
Outputs
Line outputs: 2x TRS (balanced)Output impedance: 75 ?Maximum output gain: +22 dBu
Performance
Frequency range: 10 Hz " 200 kHzEquivalent input noise (EIN): -126 dBuNoise (Mic Preamp, 150 ?, 30 dB Gain): -95 dBuNoise (Mic Preamp, 150 ?, 62 dB Gain): -68 dBuCommon mode rejection (1 kHz, Mic): >75 dBTHD+N ratio (1 kHz, 30 dB Gain): 0.003%THD+N ratio (1 kHz, 62 dB Gain, Max): 0.018%Dynamic range: 117 dBSignal LED threshold: -25 dBu
Power
Power supply: External plug-in, 12 V DC (100 V " 240 V AC input, 50 Hz/60 Hz)Internal operating voltages: +/-17 V for analog, +/-12 V for relays and LEDsPower consumption: Max 7 VA
Dimensions & Weight
Dimensions (W x H x D): 210 x 49.6 x 220 mm (8.23 x 1.95 x 8.66 inch)Unit weight: 1.5 kg (3.3 lbs)Shipping weight: 2 kg (4.4 lbs)
Additional
Made in: GermanyCompatible with SPL Marc One for monitoring and recording applications
