Soundcraft Mini-Stagebox-32R

UPC/EAN #668705000369 MPN #5049659

$3769.99

Save 16.6%, MSRP $4520.00

Financing available

Be the first to write a review

Free shipping in Canada. Conditions

32 analog mic/line inputs, 8 line out, 4 aes out remote stage box. Dual Cat5 MADI/USB. Console MADI card included

The Soundcraft Mini Stagebox 32 offers a simple and low cost solution for expanding the I/O capabilities of any of the Vi or Si range of consoles, whether that I/O is needed locally or hundreds of meters away on the stage. The Mini Stagebox 32 requires only 3U of rack space, yet provides 32 recallable mic/line inputs and 8 balanced line outputs with 4 pairs of AES outputs for a total I/O capacity of 32 inputs and 16 outputs, all lifted directly from the Vi1 and the larger Compact Stagebox.

The Mini Stagebox 32 comes fitted with a single-cable Cat 5 MADI HD interface for connection to the host console using an approved Cat 5 cable (not included). If required, this MADI HD interface card can be upgraded (sold separately) to either redundant (dual-cable) Cat 5 or redundant (dual-fibre) optical fiber with the compatible MADI HD interface card.

Features

For Vi and Si Mixing Consoles

Adds 32 Mic Line Inputs to System

Adds 16 Outputs to System

3U RU

Integrated Power Supply

MADI Card Included

Specifications

Compatible With

Vi1

Vi2

Vi4

Vi6

Vi3000

Vi5000

Vi7000

Si Impact

Si Performer

Si Expression

Si Compact

Si1, Si1+

Si2, Si2+

Si3, Si3+

Frequency Response

Mic/Line Input to any Output: +0/-1 dB, 20 Hz to 20 kHz

THD

Mic Sensitivity -30 dBu: <0.01% @ 1 kHz

Residual Noise

-85 dBu

Mic Input Noise (E.I.N.)

-125 dBu (150 Ohms Source)

CMRR

Mix Noise, Masters at Unity: < -86 dBu

1 Input to Mix at Unity Gain: -84 dBu

CMRR Mic at 1 kHz (Max Gain): -86 dBu

Crosstalk

<-80 dB at 1 kHz

Input Gain

-5 to 58 dB Integrated Pad Design 1 dB Steps

Maximum Input Level

+24 dBu

Maximum Output Level

+22 dBu

Sample Rate

48 kHz

Converter

24-Bit

Latency

1.5 ms

Clock Accuracy

+/- 25 ppm

Power Consumption

33 W

Operating Range

90 to 264 VAC, 47 to 63 Hz

Operating Temperature Range

14 to 122F / -10 to +50C

Relative Humidity

0 to 90%

Storage Temperature Range

14 to 122F / -10 to +50C

Dimensions

Not Specified by Manufacturer

Weight

Not Specified by Manufacturer

Package Weight

19.05 lb

Box Dimensions (LxWxH)

21.4 x 16.7 x 9.6"
