Sound Devices A20-SuperNexus Receiver
UPC/EAN #850032705370
MPN #28303
16/24/32-ch, SpectraBand + VHF, NexLink, RTSA, Dante, MADI, Web App, HexVersity
The A20-SuperNexus is a gamechanger. A 16-channel receiver with HexVersity (2- to 6-antenna diversity), expandable to 32 channels via software licenses " all in just a 1U 19" rack, A20-SuperNexus keeps your kit small and saves space in your rack. Take it on tour without worrying about tuning bands " it boasts a 169-1525MHz tuning range for worldwide operation. A20-SuperNexus gives you peace of mind with its RF Mirror Mode for full redundant operation.
Features
Native Dante, MADI, AES, and Analog outputsSpectraBand with 3 Tuning Bands for a total of ~72 MHz of operating bandwidth for transmittersOptional A20-Opto expansion box to add Optocore audio I/O and full redundant power suppliesSimple 1-minute operation to change countries for entire systemBuilt-in long-range NexLink remote control of all transmittersIntegrated Real Time Spectrum Analyzer (RTSA) and scanner for intuitive frequency coordinationAutoAssign: automatic deployment of multiple clean frequencies in secondsBuilt-in 6-to-2 RF combiner for multizone events6 network ports (2 x RJ45, 4 x SFP) configurable for Dante, Dante Redundancy, and ControlWeb App control from browser on any computer, smartphone, or tabletBridging between MADI, Dante, AES, Optocore, and AnalogWide, 12.4" color OLED array with touch for control and monitoringOptical Fiber Ethernet option via two SFP slots.Supports GainForward? Architecture: No gain setting on the A20 transmitter. Adjust gain at the receiver or mixer100% digital long-range modulation delivers the longest transmission distance of any digital system on the marketRF SAW filters for excellent rejection of interference transmittersExcellent audio quality; full 10 Hz " 20 kHz audio bandwidthBNC timecode input for auto timecode sync of transmitters over NexLinkThree BNC antenna input pairs, each compatible with passive, bias-powered, and smart antennas. Configurable for HexVersity or combiner modesCascade out option on rear BNCs for cascading to other receiversAutomatic Antenna zero loss loop through in the event of power loss for redundant operationFront-panel 3.5 mm and ΒΌ" headphone outputsUSB-A and USB-C ports for thumb drives, keyboards, transmitter pairing, and timecode syncing Support for USB hubsPoE+ output for powering external PoE+ powered device, including the A20-Outpost-NL
Specifications
16 channels all with HexVersity (2-, 3-, 4-, 5-, or 6-antenna diversity) in 1U rack spaceExpandable to 32 channels (all with HexVersity) in the same rack space via Software Licenses169 " 1525 MHz tuning range for full global coverageRF Mirror Mode for full redundant operation
