Solid State Logic SSL18
MPN #729748X2
Rackmount 26-in/28-out USB-C audio interface with 32-bit/192 kHz converters, 8 mic/line inputs, dual headphone outputs, 4K analogue enhancement, and advanced monitor controls
The Solid State Logic SSL 18 is a high-performance, 26-in/28-out USB audio interface, engineered to set a new benchmark for studio equipment. Built with SSL's signature craftsmanship and cutting-edge analogue and digital design, it delivers exceptional audio quality. Its 32-bit/192 kHz converters, 120 dB dynamic range across inputs, and SSL-designed mic preamps ensure pristine audio capture for recording, mixing, and producing. This rackmount interface is equipped with the innovative 4K analogue enhancement, enabling producers to imbue their tracks with the legendary SSL 4000 series sound.
SSL 18 is an all-encompassing studio centerpiece, offering versatile features such as 8 mic/line inputs, 10 balanced outputs, dual headphone outputs, and extensive digital I/O capabilities, including ADAT and S/PDIF. The integrated monitor controller with talkback functionality and Listen Mic Compressor adds further utility. With the SSL 360-powered low-latency mixer and the SSL Production Pack software bundle, it empowers creators with professional-grade tools and workflow customization. Whether you're a seasoned professional or an aspiring producer, SSL 18 provides unmatched performance and flexibility.
Features
Exceptional Audio Performance: Offers next-gen 32-bit/192 kHz converters for pristine sound quality and 120-125 dB dynamic range across inputs, outputs, and headphones.Professional Input Options: Includes 8 SSL-designed mic preamps with ultra-low noise, Legacy 4K analogue enhancement, and flexible configurations for various instruments and microphones.High-Output Capability: Provides 10 balanced line outputs with configurable levels and DC-coupled outputs for modular synth integration.Customizable Monitoring: Features dual independent headphone outputs, alternative speaker switching, and a built-in monitor controller with talkback and legendary Listen Mic Compressor.Extensive Connectivity: 26 inputs and 28 outputs via USB-C, including 16 ADAT channels, S/PDIF, MIDI I/O, and Word clock output for studio expansion.Advanced Mixing Tools: Integrated low-latency SSL 18 mixer powered by SSL 360 software for seamless input/output management, custom monitor mixes, and routing options.Legacy 4K Enhancement: Adds analogue warmth and harmonic distortion inspired by the iconic SSL 4000 series sound.Creative Production Tools: Bundled with the SSL Production Pack, offering virtual instruments, plugins, and samples worth over $1400.Flexible Operation: Includes options for loopback recording, customizable profiles, and compatibility with Mac and Windows.Exclusive Software Access: Comes with a six-month trial of the SSL Complete Access subscription for premium audio tools.
Specifications
Audio Interface Specifications
26 inputs / 28 outputsUSB-C connection compatible with Mac and WindowsNext-generation 32-bit/192 kHz converters8 microphone/line-level inputs with -130.5 dBu EIN and 67 dB gain rangeLegacy 4K analogue enhancement with harmonic distortion and high-frequency boost10 balanced line outputs; DC-coupled for control voltage integrationConfigurable output levels: +9 dBu / +24 dBu for outputs 1&2 and 3&4Dual independent headphone outputs with 120 dB dynamic range and customizable modes16 channels of ADAT I/O and 2 channels of S/PDIF I/OMIDI I/O via 3.5 mm TRS jacksWord clock output for external digital device synchronization
Monitoring and Mixing
Integrated monitor controller with Alt speaker switching and TalkbackListen Mic Compressor (LMC) with creative re-processing optionsSSL 360 software for control room mix and 4 additional monitor mixesScalable input metering and flexible Mirror Routing systemStereo Loopback with selectable loopback source
Build and Design
1U rackmount designInputs 1 & 2 include Hi-Z instrument input compatibilityConfigurable analogue insert points for external preampsAlternative speaker switching for line outputs
Audio Performance
Dynamic range: 120 dB on all inputs and headphone outputs; 125 dB on monitor and line outputsUltra-low noise microphone preampsDedicated Talkback input with multiple configuration options
Software and Compatibility
SSL 18 Low-Latency Mixer powered by SSL 360SSL Production Pack (value over $1400) included with virtual instruments, plugins, and DAW tools6-month trial of SSL Complete Access subscription featuring premium software tools
Connectivity
High-pass filters, polarity invert, and 48V phantom power per channelFlexible clocking with internal, ADAT, or S/PDIF sources
Additional Features
Customizable front panel monitoring controlsSave/Load mixer profiles for different workflowsConfigurable headphone mixes and re-purposing as line outputsStereo or mono operation for line and monitor mixes
