Sennheiser EM 100 G4 (G: 566-608 MHz)
UPC/EAN #615104366626
MPN #509654
$519.00
Save 20%, MSRP $649.00
True diversity half-rack receiver in a full-metal housing with intuitive LCD display for full control with evolution wireless G4 100 Series systems.
Features
True diversity half-rack receiver in a full-metal housing with intuitive LCD display for full control.Easy and flexible wireless synchronization between transmitter and receiver via infraredFast frequency allocation for up to 12 receivers via new linking functionalityUp to 20 compatible channelsUp to 42 MHz bandwidth with 1680 selectable frequencies, fully tunable in a stable UHF rangeTransmission Range: up to 100 meters / 300 feetHigh RF output power (up to 30 mW) depending on country regulations
Specifications
Frequency range
G: 566-608 MHz
Dimensions: Approx. 190 x 212 x 43 mm
Compander: Sennheiser HDX
THD, total harmonic distortion: 0.9 %
Weight: Approx. 980 g
Audio output
6.3 mm jack socket (unbalanced): +12 dBuXLR socket (balanced): +18 dBu
Signal-to-noise ratio: 110 dBA
Switching bandwidth: up to 42 MHz
Peak deviation: ±48 kHz
Nominal deviation: ±24 kHz
Modulation: Wideband FM
Power supply: 12 V DC
Antenna connector: 2 BNC sockets
Current consumption: 300 mA
Adjacent channel rejection: Typically 65 dB
Intermodulation attenuation: Typically 65 dB
Receiving frequency
Max. 1680 receiving frequenciesAdjustable in 25 kHz steps 20 frequency banksEach with up to 12 factory-preset channelsNo intermodulation 1 frequency bank with up to 12 programmable channels
RF sensitivity:
