Schertler YELLOW BLENDER
MPN #YELLOW-BLENDER
YELLOW BLENDER is our top preamp, offering two dedicated inputs in a robust and light aluminum case. Every single section has been engineered to ensure max. performances.
YELLOW series preamps have been specially developed to offer musicians and sound engineers flexible solutions that meet a range of performing and recording requirements. The preamps combine CLASS-A electronics with a modern, sophisticated design and lightweight yet robust aluminium housing. Every single section has been engineered to ensure maximum potential from any kind of sound source.
YELLOW BLENDER offers 2 dedicated inputs (one balanced XLR for microphones and one unbalanced Jack for instruments). The Return socket can also be used as a third input for line sources. A choice of four balanced / unbalanced output options enables connection to active loudspeakers, mixers, recording devices and effects. A separate headphone output is also provided. The two input channels include 4-band EQ, notch filter, phase reverse, low-pass "warmth" filter, low cut switch and phantom power (48V and 10V). The Send/Return sockets also enable an effect loop.
Features
Modern, sophisticated design, built in a robust and light aluminum case.Thre input channels (maximum) for all kind of microphones and pickupsFour output lines (maximum) with multiple connectionsHeadphone outputSend & Return for effect loopFour band EQ for the two main channels to ensure a wide range of tonal controlsHi-end pure class A electronics for the best possible sound performance
Specifications
Weight:
0.4 kg (0.88lb)
Dimensions:
20x10x3.8cm (7.87x4.25x1.49 in)
Frequency Response:
10 Hz to 25 kHz (+/- 3dB)
Construction:
Anodized aluminium box
MIC IN:
XLR balanced
Sensitivity: -56 dB
Impedance: 4.7 Kohm
LINE/INSTRUMENT input:
LINE IN: 1/4" Jack
Sensitivity: -52 dB
Impedance: 3 Kohm with 10V on
Impedance: 200 Kohm with 10V off
RETURN/LINE input:
1/4" stereo balanced Jack
Sensitivity: -30 dB
impedance 22 Kohm
EQ:
4 band EQ + adjustable notch filter
warm and low cut
Master outputs:
XLR balanced, output level +20 dBu
Impedance 100 ohm
1/4" Jack unbalanced, output level +14 dBu
Impedance 100 ohm
DI output:
XLR balanced, sensitivity +5 dBu
Impedance 100 ohm
SEND output:
XLR balanced, sensitivity +5 dBu
Impedance 100 ohm
Headphone:
High class headphone preamplifier
1/8" Jack, sensitivity +10 dBu
Impedance 10 ohm
Supply:
24VDC 210 mA regulated power supply
