Radial Engineering Gold Digger
UPC/EAN #676101040513
MPN #R800 1440
$529.99
Save 16.7%, MSRP $636.00
Passive 4x1 selector, use to compare 4 mics in the studio, XLR i/o
The Gold Digger is a 4-channel mic selector that enables the engineer to quickly compare the sound of four different microphones while sharing the same preamp. A 'straight wire' passive circuit design is void of any audio buffers or transformers. Instead, the Gold Digger employs military grade gold contact relays to manage the switching process, thus ensuring the pristine mic signal is maintained without introducing color, distortion or artefact of any kind.
Features include four rear-mounted XLR-F mic inputs plus an XLR-m output to feed the preamp. To eliminate bleed between microphones, each channel is equipped with a 'radio style' selector switch that ensures only one mic is on at a time. The external supply provides power for the LED indicators, charges the relays and enables the Gold Digger to generate 48 volt phantom which can be turned on or off for each mic as needed. To ensure an 'honest' comparison between microphones, individual 'set & forget' trim controls let you adjust each mic level so that they produce the same relative output. Once set up, the Gold Digger not only improves workflow, but also gives the artist more confidence with the sound of the vocal, resulting in a better overall performance.
The Gold Digger - A tool designed to get the very best out of each and every performance.
Features
Four selectable inputs with trim adjustsStraight wire distortion-free signal pathWill not introduce color or artifactIncreases artist's confidence when recording
Specifications
Audio circuit type : Passive signal path with active relay switchingFrequency response : 10Hz to 100kHz +/- 0.0dBDynamic range : >140dBEquivalent input noise : -115dBuResidual noise : -140dBMaximum input : +26dBuMaximum output : +26dBuTotal harmonic distortion : 0.0003%Phase deviation : < 0.001 Degrees at all frequenciesIntermodulation Distortion : 0.001%Input impedance : 600 Ohms (typical)Common mode rejection : -92dBu @ 55HzGain : 0.0dB - Unity gain device
Features
Inputs : 4 x XLR femaleOutputs : Balanced XLR maleSwitches : Individual on/off for each input, Individual 48V phantom power for each inputControls : Variable trim on each inputXLR configuration : AES standard (pin-2 hot)
General
Power : +15V DC/400mA power supply includedConstruction : 14 gauge steel chassis & outer shellFinish : Durable powder coatSize : (W x H x D) 4.5" x 2" x 6" (121 x 64 x 147mm)Shipping size : W x H x D : 4.75" x 2.5" x 10.75" (121 x 64 x 273mm)Weight : 2.8 lb (1.3kg)Shipping weight : 3.05 lb ( 1.4kg)Conditions : For indoor use at temperatures between +5 c and +40 c
