Presonus Revelator io44
UPC/EAN #673455009838
MPN #REVELATOR-IO44
$159.00
Save 18.5%, MSRP $195.00
1x1 USB-C interface, 24-bit/96 kHz, XMAX-L preamp, built-in mixer, FX, TRRS input, Bluetooth, streaming-ready, mobile compatible, Studio One Pro included
The PreSonus Revelator io44 is a versatile, ultra-compact audio interface tailored for creators, streamers, and musicians who want studio-grade sound in a mobile-friendly format. Featuring a premium XMAX-L mic preamp, this 1x1 USB-C interface delivers 24-bit/96 kHz audio and includes a built-in streaming mixer that lets you blend up to three different applications at once - perfect for gaming, live streaming, podcasting, or recording. With support for XLR mics, instruments, DJ gear, and even TRRS headsets, the io44 is your all-in-one solution for creating on the go or in a home studio.
Its onboard processing includes EQ, compression, gate, reverb, and vocal effects, modeled after PreSonus' StudioLive Series III mixers, allowing you to enhance your sound with zero CPU load. You can apply effects in real time for your stream, monitor mix, or print them directly to your recordings. The Universal Control app provides deep control from your desktop or mobile device, and stand-alone operation lets you keep your custom presets and processing wherever you go.
Bundled with 6 months of Studio One Pro+ and the Studio Magic software suite, the Revelator io44 is ready to deliver professional results straight out of the box. Whether you're streaming on Twitch, recording music, or podcasting from your phone, it brings reliable, high-quality performance and flexibility in a device that fits in your hand.
Features
Compact USB-C audio interface with built-in mixer and effectsIncludes professional XMAX-L mic preamp with 60 dB gain rangeConnects mics, instruments, DJ gear, and headsetsStudio-quality 24-bit/96 kHz audio resolutionOnboard reverb, EQ, compression, and voice effectsBlend audio from up to three apps for live streaming or recordingHeadset jack and stereo outputs with independent controlIncludes Studio One Pro access and Studio Magic software bundlePortable, bus-powered design for mobile and home use
Specifications
General Specifications
Product Name: Revelator io44Series: RevelatorColor: Black
Audio Interface
Type: 1x1 USB C Audio InterfaceBit Depth: 24 bitSample Rates: 44.1 48 88.2 96 kHzBus Powered: YesStandalone Mode: YesIntegrated Mixer: Supports blending audio from up to three applicationsOnboard DSP: Reverb compression EQ Voice FXPreset Storage: OnboardSoftware Included: Studio One Pro 7 Access 6 month Studio One Pro Plus and Studio Magic bundle
Inputs
Microphone Input: 1 XLR Female BalancedInstrument Input: 1 quarter inch TS Female UnbalancedStereo Line Input: 1 eighth inch TRS FemaleHeadset Input: 1 eighth inch TRRS Stereo
Outputs
Main Outputs: 2 quarter inch Balanced Left and RightHeadphone Output: 1 eighth inch TRRS StereoMain and Line Outputs Max Level: plus 10 dBuMain and Line Outputs Frequency Response: 20 Hz to 20 kHzMain and Line Outputs Total Harmonic Distortion: 0.003 percentHeadphone Output Max Power: 30 milliwatt per channel at 56 ohmsHeadphone Output Impedance Range: 32 ohms to 300 ohmsHeadphone Output Frequency Response: 20 Hz to 20 kHz
Mic Preamp
Type: XMAX LGain Range: 60 dBFrequency Response: 20 Hz to 20 kHzInput Impedance: 1.4 kilo ohmsMax Input Level: plus 10 dBu plus minus 0.5 dBuEquivalent Input Noise: minus 128 dBuTotal Harmonic Distortion: 0.005 percent at 1 kHz minus 1 dBFS minimum gain
Instrument Input
Frequency Response: 20 Hz to 20 kHzGain Range: 40 dBMax Input Level: plus 10 dBu
Power and Connectivity
Connectivity: USB C compatible USB 2.0Phantom Power: plus 48 VDC 10 milliampereVoltage Requirements: 100 to 240 VAC 50 to 60 Hz
Physical Dimensions
Width: 5.35 inches 13.6 centimetersHeight: 2.3 inches 5.8 centimetersDepth: 3 inches 7.5 centimeters
Certifications and Codes
Commodity Code: 8517620000
