Midas AS88
MPN #MIDAS-AS 88
Dual redundant HyperMAC to 8-port AES50 converter, 192 ch @ 96 kHz, dual PSU, optical/copper I/O, rugged 2U rackmount design, status LED indicators
The Midas AS88 is a powerful, rackmountable interface designed to convert dual high-speed HyperMAC connections into eight fully redundant AES50 ports, and vice versa, while supporting up to 192 bidirectional channels at 96 kHz. Engineered for ultra-fast switching and system stability, it is the ideal backbone for large-scale live sound and broadcast setups.
Designed to complement the Midas HD96 console, the AS88 enables full redundancy across both Snake ports, enhancing both system capacity and reliability. It leverages advanced FPGA-based technology for real-time failover, ensuring uninterrupted audio in the event of cable or connection loss.
Connectivity includes dual copper and optical HyperMAC inputs, 16 RJ45 AES50 outputs, and an Ethernet port for network integration. The Microprocessor-controlled redundancy management communicates with the console to indicate cable states, giving engineers full transparency and control.
Built into a rugged 2U chassis, the AS88 features dual universal power supplies with independent inlets, a factory reset button, LED status indicators for every critical function, and robust RJ45 and optical connectors. It is purpose-built to withstand the rigors of touring while maintaining exceptional performance in mission-critical environments.
Whether you're working in touring, festivals, or high-end install environments, the AS88 offers uncompromising audio transmission, seamless integration, and fail-safe operation-all in a space-efficient, road-ready design.
Features
Dual HyperMAC to AES50 Conversion: Seamlessly converts two high-bitrate HyperMAC connections into eight fully redundant AES50 ports, and vice versa.High Channel Capacity: Supports up to 192 bidirectional audio channels at 96 kHz for large-scale digital audio networks.Full Redundancy Support: Enables full failover for connected systems using advanced FPGA-based switching and dual redundancy across Snake ports.Compact and Rugged Build: Durable 2U rackmountable chassis designed for the demands of touring and live sound.Universal Power Supply: Dual redundant auto-ranging switch-mode power supply ensures reliable operation worldwide.Industry-Standard Connectivity: Uses RJ45 connectors for AES50 and copper HyperMAC, and dual-fiber optical connectors for optical HyperMAC.Easy System Monitoring: Includes status LEDs for each AES50 port, Snake connection, power supply, and Ethernet.Clock Flexibility: Can be clocked from incoming AES50 or HyperMAC ports to fit into various digital audio environments.Fast and Reliable Switching: Engineered for ultra-fast audio routing and dependable failover in professional audio systems.Ideal for Live Sound Systems: Designed to integrate seamlessly with the Midas HD96 console and other networked audio setups.
Specifications
General Specifications
Product Type: Dual HyperMAC to Dual Redundant AES50 ConverterForm Factor: 2U rackmountableArchitecture: 2 In / 16 Out (Dual redundancy)Channel Capacity: Up to 192 bidirectional channels at 96 kHzClocking: From incoming AES50 or HyperMAC ports
Connectivity - Inputs
HyperMAC Optical: 2 x standard connectors (rear panel)HyperMAC Copper: 2 x standard connectors (rear panel)Ethernet: 1 x RJ45 connector (rear panel)
Connectivity - Outputs
AES50: 16 x RJ45 sockets (rear panel)
Power & Control
Power Switches: 2 x rocker switches (rear panel)Power Inlets: 2 x IEC C13 connectors (rear panel)Power Indicator: Blue LED (front panel)Power Supply: Dual redundant auto-ranging universal switch-modeFactory Reset: Pushbutton (rear panel)
Status Indicators
Snake X Status: 2 x green / 2 x red LEDsSnake Y Status: 2 x green / 2 x red LEDsPSU Status: 2 x green / 2 x red LEDsAES50 Status: 16 x green / 16 x red LEDsEthernet Status: 1 x green LED
Display
Display Type: 2 x 20 character display
Power Requirements
Voltage Range: 100 - 240 V AC, 50 / 60 HzPower Consumption: 2 x 25 W maximum (dual redundancy)
Physical Characteristics
Operating Temperature Range: 5 degrees C to 45 degrees C (41 degrees F to 113 degrees F)Dimensions (H x W x D): 88 x 440 x 483 mm (3.46 x 17.32 x 19.01 inches)Weight: 6.59 kg (14.53 lbs)
