Audio Technica AT2050
UPC/EAN #4961310101763
MPN #AT2050
The Audio-Technica AT2050 provides consistent, superior performance in switchable cardioid, omnidirectional and figure-of-eight polar pattern settings.
Its dual large diaphragms are gold-vaporized and aged to achieve optimum characteristics over years of use. Equipped with a switchable 80 Hz high-pass filter and 10 dB pad, the microphone is ideal for studio and live sound use on vocals, piano, strings, drum overheads, guitar amps, and more.
Features
Three switchable polar patterns: omni, cardioid, figure-of-eightSwitchable 80 Hz high-pass filter and 10 dB padLarge diaphragm for smooth, natural sound and low noiseState-of-the-art surface-mount electronics ensure compliance with A-T's stringent consistency and reliability standardsIncludes shock mount & protective pouch
Specifications
ELEMENT
Externally-polarized (DC bias) condenser
POLAR PATTERNS
Cardioid,
Omnidirectional,
Figure-of-Eight
FREQUENCY RESPONSE
20-20,000 Hz
LOW FREQUENCY ROLL-OFF
80 Hz, 12 dB/octave
OPEN CIRCUIT SENSITIVITY
Â-42 dB (7.9 mV) re 1V at 1 Pa
IMPEDANCE
120 ohms
MAXIMUM INPUT SOUND LEVEL
149 dB SPL, 1 kHz at 1% T.H.D.;
159 dB SPL, with 10 dB pad (nominal)
NOISE
17 dB SPL
DYNAMIC RANGE (typical)
132 dB, 1 kHz at Max SPL
SIGNAL-TO-NOISE RATIO
77 dB, 1 kHz at 1 Pa
PHANTOM POWER REQUIREMENTS
11-52V DC, 4.7 mA typical
SWITCHES
Polar selection;
Flat, roll-off; 10 dB pad (nominal)
WEIGHT
412 g (14.5 oz)
DIMENSIONS
170.0 mm (6.69") long,
52.0 mm (2.05") maximum body diameter
OUTPUT CONNECTORS
Integral 3-pin XLRM-type
ACCESSORIES FURNISHED
AT8458 shock mount for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; soft protective pouch
AUDIO-TECHNICA CASE STYLE
R5
