Audient iD48
Compact audio interface with dual mic preamps, high-resolution 24-bit/96kHz audio, ultra-low latency, independent headphone and speaker outputs, and USB-C connectivity
Bigger, better and more powerful than ever, iD48 is the flagship USB iD interface made for producers and engineers. Packing in eight Audient Console Mic Preamps, advanced 32-bit ESS converter technology and the all new Switchable Analogue Insert technology, iD48 seamlessly combines astonishing audio performance with ease of use. Add to that professional must have features like ADAT expandability and customisable monitor control, iD48 is ready to transform your studio.
Sound better than ever with the Audient Console Mic Preamp. Delivering 68dB gain, ultra- low noise and low distortion with a touch of classic analogue warmth. iD48's eight Audient Console Mic Preamp's make sure you capture a clean, accurate and true to source translation of your audio.
Next-level performance
Utilising 32-bit ESS DAC converter technology to minimise quality loss and maximise performance during conversion, iD48 makes sure your audio sounds cleaner, clearer and more precise than ever. And with 126.5dB of dynamic range, you will hear subtle details better and identify problematic issues faster " making getting release ready results easy.
Features
24 Inputs32 Outputs (24 Simultaneous Outputs over USB)8 x Class-A Audient Console Mic PreampsClass Leading AD/DA Converters2 x Discrete JFET Instrument InputsMain and Alt Speaker Outputs2 x Independent Headphone Outputs2 x ADAT Input & Outputs8 x Switchable Balanced InsertsUltra-low Latency Software MixerAudio Loop-backScrollControlDedicated Alt Speakers and Talkback Controls2 x User Defined Function Keys+48V, Pad, +10dB Boost, Polarity Invert and HPF ControlsWord Clock Input & OutputStandalone ModePower On/OffUSB 2.0 Compliant (24in / 24out)24bit/96kHzDetachable Rack EarsAll-Metal DesignFree Software & Plugins
Specifications
Analogue to Digital Converter
? Maximum Input Level: +18dBu (0dBFS digital maximum)
? Digital Reference Level: +18dBu = 0dBFS
? Input Impedance: >10k? balanced
? Crosstalk: <-118dB @ 1kHz, <-115dB @ 10kHz
? Frequency Response: ±0.5dB 10Hz to Fs/2 (Nyquist)
? THD+N @ -1dBFS (1kHz): <0.0003% (-110dB)
? Dynamic Range: 120dB A-weighted
? 1/4" TRS Jack: Tip (Hot), Ring (Cold), Sleeve (Shield)
Digital to Analogue Converter (Monitor and Line Outputs)
? Maximum Output Level: +18dBu (0dBFS digital maximum)
? Output Impedance: <100?
? Crosstalk: <-120dB @ 1kHz, <-115dB @ 10kHz
? Frequency Response: ±0.5dB 10Hz to Fs/2 (Nyquist)
? THD+N @ -1dBFS (1kHz): <0.00026% (-111.5dB)
? Dynamic Range: 124dB un-weighted, 126.5dB A-weighted
? 1/4" TRS Jack: Tip (Hot), Ring (Cold), Sleeve (Shield)
Headphone Outputs
? Maximum Output Level: +18dBu (0dBFS digital maximum)
? Output Impedance: <50? unbalanced
? Crosstalk: <-117dB @ 1kHz, -112dB @ 10kHz
? Frequency Response: ±0.5dB 10Hz to Fs/2
? THD+N @ -1dBFS (1kHz): <0.00023% (-112dB)
? Dynamic Range: 121dB un-weighted, 124dB A-weighted
? Max Level Into 30?: 4V Peak, 2.85V RMS, 530mW
? Max Level Into 60?: 5.82V Peak, 4.12V RMS, 565mW
? Max Level Into 600?: 8.71V Peak, 6.16V RMS, 126mW
? 1/4" Jack: Tip (Hot), Ring (Cold), Sleeve (Shield)
