The ATC Loudspeakers SCM150ASL Pro is a further development of the SCM100ASL Pro, featuring an extended bass, greater headroom and a higher dynamic range.
The SCM150ASL Pro substitutes a larger 375mm Super Linear bass driver and increases the enclosure size to 150 litres, adding an extended band with and high dynamic range. These monitors offer medium sized studios the classic ATC quality constuction, and the accurate and aritculate sound needed for producing complex and well balanced mixes. the SCM150ASL Pro are one of the best investments any studio can make.
Caractéristiques
ATC 25mm/1" Dual Suspension 'S-Spec' Tweeter.
Full "SL" spec 15/375mm bass driver.
ATC 75mm "Super Dome" mid driver.
On board ATC grounded source 350W Tri-Amp Pack.
LF contour control.
Clip indication.
Spécifications
Drivers: HF 1/25mm, Mid 3/75mm, LF 15/375mm Amplitude Linearity (±2dB): 60Hz-17kHz Cut-off Frequencies (-6dB, free-standing): 25Hz, 22kHz Horizontal Dispersion: ±80, Coherent Vertical Dispersion: ±10, Coherent Max. Continuous SPL (1 metre): 117dB Crossover Frequencies: 380Hz, 3.5kHz Input Connectors: Male XLR Input Sensitivity: 1V Input Sensitivity Trim: 0dB to -6dB/1V - 2V (continuously variable via rear panel trimmer) Input Impedance: Balanced > 10k Amplifier Output: Bass 200W, Mid 100W, High 50W Filters: Even Order Critically Damped Overload Protection: Active FET momentary gain reduction plus thermal tweeter protection Front Panel Indicators: Power On indicator, Gain Reduction warning LF EQ: 0dB to+6dB @ 40Hz (continuously variable via rear panel trimmer) Dimensions (HxWxD): 884 x 498 x 568mm (34.8 x 19.6 x 22.4) Depth with amplifier at rear adds 3 Weight: 75kg / 165lbs
