Apogee Symphony I/O MKII SoundGrid Chassis
UPC/EAN #805676302140
MPN #SYM2-SG
Chassis with SoundGrid connectivity, modular I/O ready, premium AD/DA conversion, low latency, immersive audio support, touchscreen control, Dante compatible
The Symphony I/O MkII SoundGrid Chassis is Apogee's premier modular interface configured specifically for integration into Waves SoundGrid networks. Built around Apogee's acclaimed AD/DA conversion, this chassis provides the core of a scalable, high-performance system for studio professionals who rely on real-time plugin processing, live sound setups, or distributed audio environments.
Designed with flexibility in mind, this chassis allows users to populate it with Apogee's modular I/O cards to suit a variety of audio production needs, supporting up to 32 inputs and outputs. It includes a SoundGrid connectivity card, enabling direct interfacing with Waves SoundGrid-compatible systems. Whether for broadcast, recording, or live environments, the Symphony I/O MkII SoundGrid chassis delivers pristine audio quality, rock-solid low-latency performance, and streamlined operation through its intuitive touchscreen control.
Features
Symphony Mk II chassis equipped with Waves SoundGrid connectivity.Designed for real-time audio networking in SoundGrid-compatible environments.Supports up to 32 channels of modular analog I/O with optional I/O modules.High-resolution touchscreen for easy navigation and system control.Offers top-tier AD/DA conversion with ultra-low latency performance.Ideal for studio and live applications using Waves plugins and SoundGrid servers.Compatible with Mac and PC through the SoundGrid platform.Built in the USA for robust, professional studio reliability.
Specifications
General Specifications:
Product: Apogee Symphony Mk IIModel: Symphony I O MKII SoundGrid chassisConfiguration: Chassis only with integrated Waves SoundGrid connectivity, no I O modules includedDisplay: Intuitive touchscreen interfaceModularity: Supports up to 32 channels of modular analog I O via user-selected cardsPower: 90 to 240 VAC, 50 to 60 Hz, 150 WBuild: Designed and built in the USA
Connectivity:
Platform: Waves SoundGridCompatibility: Waves SoundGrid host systemsExpansion Options: Can be upgraded with Thunderbolt or Pro Tools HD Plus and Dante cards
Digital Conversion Specifications (requires I O modules):
Analog to Digital THD plus N: minus 115 dB at 22 dBu unweightedAD Dynamic Range: 122 dB A weightedDigital to Analog THD plus N: minus 119 dB at 21 dBu unweightedDA Dynamic Range: 126 dB A weightedFrequency Response: 44.1 kHz to 20 kHz plus minus 0.05 dB
Headphone Output:
Connector: 1 stereo quarter inch front panelTHD plus N: minus 110 dB at 19 dBu into 600 Ohm, minus 101 dB at 14 dBu into 32 OhmDynamic Range: 121 dB A weightedOutput Design: Apogee Constant Current Drive
Monitor Control and Immersive Audio:
Requires Thunderbolt module for full Monitor Workflows and immersive audio supportModular configuration allows future expansion
Use Case:
Ideal for studios integrating Apogee's high-end conversion with Waves SoundGrid systemsEnables remote DSP networking and flexible routing
Chassis Role:
Foundation for a fully customizable audio interface with user-defined analog and digital I O modulesRequires I O cards to enable input output functionality
