ALLEN & HEATH  |  SKU: 10279

WZ4 12:2

4 to 16 Channels Boards

Compact analog mixer with 12 inputs, 2 outputs, and robust EQ options, delivering reliable performance for live sound and studio applications.

$1,899.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The 2 dual stereo channels are perfect for stereo playback or for hooking up keyboards and other stereo instruments. WZ4 12:2 features our acclaimed 4 band EQ with 2 sweepable mids, high quality 100mm faders, 6 aux sends, 12 segment bargraph metering and our unique QCC connector system for easy desktop, rack or flightcase mounting.

New features for this 4th generation MixWizard console include two newly designed digital FX engines with 20 studio quality FX presets, EQ in/out switching and the option to fit a multichannel USB interface with high quality 16 channel soundcard for easy multitrack recording and 2-track playback.

If you're looking for professional grade, all-purpose analogue mixers in a compact, rack mountable frame, the MixWizards continue to set the bar.

Features

19" Rack mountable

8 mic/line inputs with balanced XLR/TRS jack, insert and direct output

100mm faders

2 Dual Stereo inputs with separate gain and 'ON' switches allowing inputs to be selected independently or mixed together

4 band EQ with 2 swept mids

6 Aux sends - 2x pre fade / 2x switched / 2x post fade

2 Stereo returns

Dedicated mono output fader - can be switched to provide an L+R mono feed for a centre or fill speaker, or sub bass feed

Independent A-B output for 2-track recording, monitor foldback, speaker fills etc

Tri-colour, 12 segment bargraph metering

Twin FX engines with 20 studio quality FX presets

+48V Phantom Power

Signal and Peak LEDs

Lamp socket

USB multitrack recording option

Footswitch connector (mutes/unmutes the ST1 FX Return)

Specifications

Inputs: 8 mono mic/line inputs with balanced XLR/TRS jacks; 2 dual stereo channels; 2 stereo returns

Outputs: Main mix outputs on balanced XLR; 6 auxiliary sends; 2 stereo returns; dedicated mono output

EQ: 4-band EQ with 2 sweepable mid frequencies on mono channels; 4-band fixed EQ on stereo channels

Faders: 100mm high-quality faders for precise level control

Built-in Effects: Dual stereo FX engines with 20 presets; editable parameters and tap tempo function

Metering: 12-segment bargraph meters for accurate signal monitoring

Construction: Rugged build with QCC connector system for easy desktop, rack, or flight case mounting

Dimensions: Width: 507 mm; Depth: 530 mm; Height: 194 mm

Weight: Approximately 11 kg

Additional Features: 6 auxiliary sends for versatile routing; individual channel inserts and direct outputs; 48V phantom power on mic inputs; USB multitrack recording capabilities

Applications: Suitable for live sound reinforcement, studio recording, and installations requiring a compact, high-quality analog mixer
