Zoom LiveTrak L-6
UPC/EAN #4515260029921
MPN #ZL6
6 channel mixer with dual A/D converters, 32-bit float recording, MIDI compatibility, USB interface, and customizable sound pads. Perfect for studio and field use.
The Zoom LiveTrak L6 is a versatile digital mixer and recorder, ideal for musicians, podcasters, and live performers. It features six channels, with dual A/D converter circuits on channels 1 and 2, providing high-quality audio without the need for manual gain adjustments. The L6 supports multi-track recording in 32-bit float WAV format, preserving audio integrity during mixing and editing. It can be powered via USB or batteries, making it portable for field use. Additionally, the L6 offers scene-saving, sound pad control, and integration with MIDI devices and apps<.
Features
High-Quality Audio Mixing: Features dual A/D converters and 32-bit float format to ensure optimal audio quality for both loud and quiet sounds without manual gain adjustments.Multi-Channel Input: Supports up to 6 input channels, allowing the connection of microphones, instruments, and synthesizers. Inputs 1 and 2 offer dual A/D converters.Recording in 32-bit Float Format: Record high-quality audio in 32-bit float WAV files to preserve audio quality even during post-editing.Internal and External Effects: Built-in effects like reverb and delay, with support for connecting external effects for added flexibility.Scene Saving: Save and recall mixer settings for quick access to presets during live performances or recording sessions.Sound Pads: Assign and trigger audio files using 4 sound pads, with customizable playback modes such as one-shot or loop.Recording and Playback: Records multi-track audio onto a microSD card while allowing playback of recorded files directly from the device.USB Audio Interface: Functions as a USB audio interface for computers, smartphones, or tablets, enabling multi-channel audio input and output.MIDI Support: Offers MIDI input/output functionality for integration with MIDI devices and DAWs.Portable Power Options: Operates on AA batteries, USB bus power, or an AC adapter, making it versatile for studio and field use.
Specifications
General
Mixer and recorder with 6 channelsDual A/D converter circuits on inputs 1 and 232-bit float WAV file recording formatBuilt-in sound pads with 4 assignable buttonsInternal and external effects supportCan be powered by batteries, USB, or AC adapterInputs
Mono inputs: 2 XLR/TRS combo jacksStereo inputs: 4 TS jacksInput impedance: 3.8 k? (XLR), 39 k? (TRS), 10 k? (stereo)Maximum input level: +4 dBu (XLR), +24 dBu (TRS), +9 dBu (stereo)+48V phantom power support
Outputs
AUX Sends: 2 TRS balanced outputsMASTER: 1 stereo TRS balanced outputMONITOR: 1 stereo TRS headphone outputMaximum output level: +9.5 dBu (AUX), +15 dBu (MASTER), 50 mW + 50 mW (MONITOR)Output impedance: 147 ? (AUX, MASTER), 14.7 ? (MONITOR)
Recording
Supports microSDHC and microSDXC cards (Class 10 or higher)Simultaneous recording tracks: 12Simultaneous playback tracks: 2Recording format: 48 kHz, 32-bit float, WAV (mono or stereo)
Audio Interface
USB 2.0 interfaceInput channels: 12Output channels: 4Sampling frequency: 48 kHzBit depth: 32-bit float or 24-bit selectableCompatible with Mac, Windows, iOS, and Android
Effects
5 internal effects: Hall Reverb, Room Reverb, Spring Reverb, Digital Delay, Tape EchoAdjustable effect parameters via ZOOM L6 Editor software
EQ
High: 10 kHz, ±15 dB, shelvingMid: 100 Hz " 8 kHz, ±15 dB, peakingLow: 100 Hz, ±15 dB, shelving
Power
4 AA batteries (alkaline, NiMH, or lithium)USB bus power supportAC adapter (ZOOM AD-17, 5V/1A)Battery life: 3 hours (alkaline), 3.5 hours (NiMH), 7 hours (lithium)
Dimensions and Weight
Dimensions: 223 mm (W) - 114 mm (D) - 46.5 mm (H)Weight: 526 g (without batteries), 618 g (with batteries)
