Solid State Logic Origin 16
MPN #Origin 16
16 in-line channel analog console with two independent signal paths per channel, 16 buses with centralized bus switching and advanced communications controls
With its legendary sound and powerful features, ORIGIN 16 is the most comprehensive analogue console in its class and the ultimate solution for a hybrid, DAW-based workflows where console automation is not required. Sharing the same centre section as the bigger 32 channel variant, ORIGIN 16 draws on traditional in-line consoles for inspiration, while leveraging SSL's latest cutting-edge analogue design.
ORIGIN 16's simple signal flow and layout make it easy to understand and use, while powerful features such as channel direct outputs, a fully balanced electronic architecture and precision bargraph meters make it an ideal companion for even the highest quality converters and the most demanding professional production applications.
Similar to its larger sibling, an innovative modular centre section allow ORIGIN 16 to adapt to different applications " for instance a tracking console with additional boutique analogue processing to its 19" rack centre section, or a more digital/analogue hybrid approach with screens and controllers such as the SSL UF8 Advanced DAW Controller " all of which are easily reached from the listening position. ORIGIN 16's ultra-low power consumption and innovative power saving features equal lower operational costs for smaller rooms and musician-based project studios.
Stunning audio performance
ORIGIN 16's PureDrive microphone preamplifier provides a wide range of sonic options, bringing unparalleled flexibility whether using it for tracking or mixing. Users can attain ultra-clean to driven sounds present in previous SSL mic pre designs, but also engage a warmer, more harmonically rich tone by activating the "Drive" function.
ORIGIN 16 also uses a classic SSL EQ design made famous on its previous generations of consoles. The E-Series '242' EQ was probably the most popular EQ from the SL 4000 Series console range, and this design was also present in several SSL console designs that followed, including the G-Series. A built-in classic SSL Bus Compressor, with sidechain access and HP filter, make ORIGIN 16 the perfect solution for mixing and summing.
Features
16 mono in-line channels / 16 track busses / 8 stereo subgroups / total of 56 inputs at mixdown.Same master section and monitoring options as 32 channel ORIGIN.PureDrive mic pre inherits the clarity and purity of previous SSL Mic Pre designs, and can switch to a warm, harmonically rich and driven tone that varies with mic pre gain when the "Drive" function is activated.Mix bus and mix amp architecture delivers an amazingly low noise floor, huge headroom along with SSL's latest summing bus technology that retains the classic SSL sound while bringing the breadth and space to mixes.Acclaimed SSL E-Series ?242 type' four band parametric channel EQ.Classic SSL Bus Compressor with sidechain access and HP filter.Balanced Insert Point per Large Fader and Small Fader Channel Paths.Dedicated Channel Direct Output make it easy to print mixes to the workstation.Modern circuit designs and unique power management tools deliver ultimate reliability and low running costs.
