Shure SLXD4-G58
UPC/EAN #042406556767
MPN #SLXD4-G58
$1219.00
Save 20.2%, MSRP $1528.00
Single digital receiver with PS43US power supply, 1/4-wave antennas, and rackmounthardware. Frequency Range (44MHz) 470-514.
The Shure SLXD4 Digital Wireless Receiver - G58 is a single-channel, half-rack unit engineered to deliver reliable, high-fidelity wireless audio for presentations, performances, and events. Operating in the 470"514 MHz frequency range, this receiver features a robust 44 MHz tuning bandwidth, allowing for up to 32 compatible channels per band. Its 24-bit digital audio and wide 20 Hz to 20 kHz frequency response ensure transparent, studio-quality sound suitable for a wide variety of applications.
Designed with professional performance in mind, the SLXD4 includes Shure's digital predictive switching diversity for enhanced signal stability, intuitive IR sync for easy transmitter pairing, and Ethernet connectivity for streamlined setup and control via Wireless Workbench or the ShurePlus Channels app. With its rugged metal chassis, clear LCD interface, and support for interchangeable microphone capsules, the SLXD4 is built to integrate seamlessly into demanding production environments-from conference rooms to houses of worship and live venues.
Features
Single-channel wireless receiver with 24-bit digital audioWide 20 Hz to 20 kHz frequency response and 118 dB dynamic rangeOperates in the 470"514 MHz UHF band with 44 MHz tuning bandwidthSupports up to 32 channels per band and 10-12 systems per TV bandQuick transmitter pairing via IR sync and automatic channel scanningCompatible with Shure Wireless Workbench and ShurePlus Channels appEthernet port for group scanning, firmware updates, and third-party controlGuided setup mode and high-contrast LCD menu for ease of useDurable galvanized steel housing with included rackmount hardwareUp to 8 hours battery life with AA or optional rechargeable battery
Specifications
General Specifications
Product Name: SLXD4 Digital Wireless ReceiverSKU: SLXD4-G58Receiver Type: Single channel half rackFrequency Band: G58 470 to 514 megahertzHousing: Galvanized steelDisplay: High contrast LCDCompatibility: SLX D wireless systems and transmittersCapsule Compatibility: Interchangeable microphone capsulesSoftware Support: Shure Wireless Workbench 7 and ShurePlus Channels mobile appSetup Features: Guided setup mode, automatic channel scan, IR scan and sync
Audio Performance
Audio Resolution: 24 bit digital audioFrequency Response: 20 hertz to 20 kilohertz microphone dependentDynamic Range: 118 decibelsGain Adjustment Range: 18 to 42 decibels in 1 decibel stepsMic Line Switch: 30 decibel padPhantom Power Protection: Supported on quarter inch and XLR outputs
RF and Wireless Specs
Diversity Technology: Digital Predictive Switching DiversityTuning Bandwidth: 44 megahertzChannels per Frequency Band: Up to 32Compatible Systems: Up to 10 per 6 megahertz TV band, 12 per 8 megahertz TV bandSpurious Rejection: Greater than 75 decibels typicalRF Input Connector: BNCRF Input Impedance: 50 ohms
Inputs and Outputs
Audio Outputs: XLR balanced and quarter inch balancedQuarter Inch Output Impedance: 1.3 kilo ohms balanced, 670 ohms unbalancedXLR Output Impedance Line: 400 ohms balanced, 200 ohms unbalancedXLR Output Impedance Mic: 150 ohmsFull Scale Output Quarter Inch: Plus 15 dBV differential, plus 9 dBV single endedFull Scale Output XLR Line: Plus 15 dBVFull Scale Output XLR Mic: Minus 15 dBV
Networking
Network Interface: Single port Ethernet 10 100 MbpsAddressing Options: DHCP or manual IPMaximum Cable Length: 100 meters
Power and Battery
Power Requirement: 15 VDC at 600 milliampsPower Supply: External with tip positiveBattery Options for Transmitters: Two AA batteries or Shure SB903 rechargeable batteryBattery Life: Up to 8 hours
Dimensions and Weight
Height: 42 millimetersWidth: 197 millimetersDepth: 152 millimetersWeight: 816 grams without antennas
Included in the Box
One single channel receiverTwo quarter wave antennasTwo bulkhead adaptersTwo 22 inch BNC cablesOne power supplyTwo short rack mount bracketsOne hardware kit
