RME 12Mic
UPC/EAN #4260123363291
MPN #12Mic
12-channel, digitally controlled high-end mic preamp with integrated MADI and AVB
The RME 12Mic is a twelve channel remote controllable microphone preamplifier with no-compromise A/D conversion, integrated AVB and MADI connectivity and a multitude of features designed to make it a perfect companion for any professional recording.
The PAD-free microphone input stages have a 75 dB gain range and accept signals of up to +18 dBu. On the conversion side, the extraordinary SNR values show anastonishing 121.2 dB(A) on all channels. All twelve front-facing XLR connections accept microphone and line level signals, whilst the first four connections also accept TRS connectors, with switchable high impedance (Hi-Z) for instruments.
Both coaxial and optical (via an SFP module) MADI I/O is available for independent or redundant operation, and can be used for daisy chaining, merging and converting MADI signals at incredibly low latency. Three optical ADAT outputs provide up to 24 channels of audio at single speed (for example, a combination of microphone inputs, MADI signals and AVB signals), or 12 output channels at 96 kHz sampling rate, ensuring compatibility with a wide range of audio interfaces. Additionally, the ADAT ports can also be used to send monitor mixes from the AVB or MADI inputs to existing DACs/headphone amps.
Specifications
4x XLR-TRS combo inputs (switchable P48 on XLR / Hi-Z on TRS)8x XLR microphone inputs (switchable P48)All analog inputs +18 dBu, 75 dB gainPhones output for monitoring of all signals (stereo or balanced mono)Word Clock I/O (BNC)2x RJ45 1 GigE AVB, 8 streams (each up to 16 ch.) per direction with redundancy1 x MADI I/O coaxialMADI optical via optional SFP moduleMADI input redundancy (requires optional SFP module)3x ADAT outputs (24 ch. @ 48k, supports up to 192 kHz)Internal routing of up to 268x282 channels19" enclosure 1 unit height1,54" full color display with control knob and four buttons for convenient, direct access to all featuresSteadyClock FS - ultra-low jitter digital clock technologyRemote control via HTTP, JSON, IEEE 1722.1 AVDECC, MIDI over MADIinternal PSU, optional 12V DC redundant power supplyUSB 2.0 (for remote control and firmware updates)
