RADIAL ENGINEERING  |  SKU: 23399

Highline

D.I.

Passive line isolator designed to connect guitar and amp modelers to a mixer for live touring and recording applications, featuring premium Jensen transformers

$219.99 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

Retain the Full Output from your Pedalboard or Amp Simulator

  • No loss of signal strength or tone when connecting to a mixer.
  • Radial's renowned reliability and build quality.
  • Precision-wound Jensen Transformer delivers exceptional clarity and warmth.
  • Passive, plug-and-play design requires no external power.
    • Amp simulators are more popular than ever, but they present a unique set of problems for guitar and bass players who want to interface them with a PA system. While amp sims can produce line-level outputs, they often have ¼" unbalanced connectors that aren't designed for long cable runs, and they encounter hum and buzz from ground loops when connected directly to the PA.

    The Radial Highline is ideal for players who utilize amp simulators on their pedalboard. The Highline features premium Jensen 1:1 transformers that retain the full volume from the amp sim while providing isolation that breaks up ground loops and protects against phantom power, along with a balanced output that can be run over long distances without signal degradation

    Features

    Compact & pedalboard friendly design
    No loss of signal strength or tone when connecting to a mixer
    Radial's renowned reliability & build quality
    Precision-wound Jensen Transformer
    Ability to sum stereo sources down to mono

    Specifications

    Audio circuit type: Passive, transformer-based
    Transformer: JT-11-YMPC
    Number of channels: Single channel (mono)
    Frequency response: 20Hz ~ 20kHz (±0.05dB)
    Total harmonic distortion: <0.03% from 20Hz ~ 20kHz / -10dB, 0.0002 @ 1kHz / -10dB
    Phase deviation: ±0.3 from 20Hz ~ 20kHz / -10dB
    Signal to noise: 110dB

    Features:


    Ground lift
    Input Sum
    Thru Sum

    General Specifications:


    Construction: 14-gauge steel outer shell & 16-gauge chassis
    Finish: Durable powder coat
    Dimensions (L x W x D): 4.25" x 2.75" x 1.75" (108mm x 70mm x 44mm)
    Shipping dimensions (L x W x D): 6.5" x 4" x 3" (165mm x 102mm x 76mm)
    Power: Passive, no power required
    Operating conditions: For use in dry locations only between 5C and 40C
