Radial Engineering DiNET DAN-RX2

UPC/EAN #676101044801 MPN #R800 1065

$689.99

Save 16.7%, MSRP $828.00

Financing available

Be the first to write a review

Free shipping in Canada. Conditions

Dante network receiver, Ethercon input with stereo XLR analog outputs

Robust digital audio distribution
The DAN-RX2 is a road-worthy digital receiver capable of delivering two channels of analog audio to any location from a Dante or AES-67 compliant network. Balanced XLR outputs include a ground lift and a separate headphone amp with its own level control is included for local testing or personal monitoring. The RJ45 network connection is compatible with Neutrik etherCON connector carriers to prevent accidental disconnection and protect cable terminations. Redundant powering is available for critical applications by using the included external power supply and Power over Ethernet (PoE) simultaneously, and the DAN-RX2 can be mounted in 19" equipment racks with the optional SA series rackmount adaptor kit.

Features

Stereo analog output device for Dante networks

Balanced XLR outputs for connection at mic or line level

Built-in headphone amplifier for personal monitoring

24bit/96kHz digital to analog conversion

Compliant to AES67 specifications

Specifications

Specifications
Audio circuit type: High current balanced active output device
Number of channels: 2
Frequency response: 20Hz-20kHz
Dynamic range: >100dB
Gain: +18dBu max @ 0dBFS
Total harmonic distortion: 0.007% @ -6dBFS
Output Impedance: 150
Noise: 44.1kHz, 48kHz, 88.2kHz, and 96kHz

Features
Input Connectors: 2x XLR male, 1x 3.5mm & 2x 1/4" headphone out
Output Connectors: 2x XLR male, 1x 3.5mm & 2x 1/4" headphone out
Extras: Bit Depth: 24 bit; Idle Channel Noise: -108dB; Channel Separation: >75dB; Power Consumption: 1.25W; Power over Ethernet (PoE): Class 1 IEEE 802.3af

General
Construction: 14-gauge steel
Finish: Durable powder coat
Size (L x W x D): 4.5" x 2" x 6" (121 x 6 x 147mm)
Power: 15VDC 400mA (included) or PoE
Conditions: For use in dry locations only between 5°C and 40°C
