BAE 1073 - MP Stereo Channel with PSU
MPN #DUAL73MPWPS
The BAE 1073 MP Stereo preamp yields a really fat sound. It seems to add subharmonics to the low end which makes the bottom end sound huge.
This is the mic pre-amp version of the 1073 equaliser having the same well-known characteristic Class A sound with its harmonically rich low end, slight resonant highs, and maintained focused mids.
A Carnhill transformer coupled input, with two selectable impedances makes the 1073MP work well with a variety of microphones.
There is also a line input feature for adding depth to 2-bus mixes and a DI input for all passive and active instruments.
As a coloured and versatile mic-pre, the 1073MP maintains its sonic signature across a wide bandwidth.
Features
Two Class A preamps with direct inputs in a single rack space with a power supplyHigh Impedance direct input for guitar and synthesizerOutput level control serves as gain trim between the 5 dB steps on gain switchBalanced mic input and balanced +4 dB output are on XLR connectors on the rear of the module.Similar Class A preamp as Neve* 1073 equalizer/preamp modulesPad is an integral part of the gain switch same as Neve* 1073 equalizer/preamp modulesOversize remote power supply can operate up to four channels of preampPhase reverse buttonImpedance select between 1200 and 300 ohmsDirect input switchBalanced line input48v phantom power
Specifications
Frequency Response
10Hz to -3dB at 55kHz
Mic Input Impedance
1200/300 ohms
Line Input Impedance
10k ohms
DI Input Impedance
150k ohms
Output Impedance
65 ohms
Common Mode Rejection Ratio
100dB min @ 60Hz
Maximum Output Level
+27.4 dBu @ 600
Power Requirements
115/230 VAC, 30W
Gain dB
0 to 71 dB
Equivalent Input Noise
-110 dBu; Unweighted 300kHz Bandwidth
Weight (Single/Dual)
8 LBS/3.63 KG
10 LBS/4.54 KG
Dimensions (Inches)
19W x 1.75L x 9D
