Avid Pro Tools | Carbon Hybrid Audio Production System
UPC/EAN #9900-74103-20
MPN #9935-73106-00
The Avid Pro Tools | Carbon is a 1U 24/32 hardware interface with 8 mic preamps and 115 AAX DSP plugins included
For artists, bands, and producers, Pro Tools | Carbon is a new breed of audio interface-built to capture brilliance. It's a hybrid audio production system that features incredible sound quality and combines the power of your native CPU with onboard HDX DSP acceleration. So you can push your computer to the limit when you mix and record through AAX DSP plugins with near-zero latency monitoring. All at the touch of a button. All in Pro Tools.
Hardware and software. Made for each other.
With intelligent Pro Tools integration, you'll work smoothly all in one creative environment. The Hybrid Engine lets you offload real-time AAX DSP plugin processing to Carbon at will. This means you can record with a polished sound that brings out the best in your performance. No more third-party apps to slow you down. Just focus on the music you're making-not what you're making it with.
The best in both worlds.
The Hybrid Engine maximizes the performance of Pro Tools by using your native CPU and HDX DSP processing at the same time. When you put a track in DSP Mode, Carbon accelerates real-time AAX DSP plugins while your CPU plays back the rest of your mix. And because every AAX DSP plugin has a native counterpart, you can move seamlessly between worlds-just click a button. Record with HDX DSP power for near-zero latency monitoring. And work natively with the same plugins.
Premium plugins included.
In addition to the 116 AAX plugins that come with Pro Tools-which include the Avid Complete Plugin Bundle, HEAT, and UVI Falcon-Carbon comes with a collection of premium plugins and sounds to get you started. Produce with virtual instruments from UVI and Native Instruments. Emulate mix environments with spatial audio processing from Embody. Dial in polished sounds with premium AAX DSP dynamics, EQs, and reverbs from McDSP, Arturia, and Plugin Alliance. And get 3 free months of Auto-Tune Unlimited. Then when you're ready to take your sound further, there are thousands of AAX plugins and over 250 more AAX DSP available.
Features
Seamless integration with Pro Tools and Pro Tools UltimateMerges native CPU and 8 HDX CPU cores for maximum performanceMonitor and record through AAX DSP plugins near-zero latencyIncludes 115 AAX DSP plugs from the Avid Complete CollectionSoftware package with virtual instruments and hardware emulations from UVI, Native Instruments, McDSP, and Plugin Alliance8 newly designed transparent mic preamps with variable impedance on inputs 5-8Flexible I/O including 4 headphone outputs, 8 line inputs and outputs, 16 channels of digital I/O over ADAT, and word clock I/OAVB connection offers vanishingly low latency and 32-bit float precision audio streaming
Specifications
SYSTEM REQUIREMENTS
Avid-qualified Ethernet or Thunderbolt-equipped Mac computer (see details)
INPUTS
Combo Mic/Line Inputs
8 balanced XLR/TRS with Variable Z (impedance) on inputs 5-8
DB25 Line Inputs
8 balanced via 25-pin D-sub
Instrument (Variable Z) Inputs
2 unbalanced ¼-inch TS
Digital Inputs
ADAT: 16 channels @ 44.1-96 kHz
ADAT: 8 channels @ 176.4-192 kHz
A/D CONVERSION
Mic Preamps
Dynamic Range: 126 dB (A-weighted)
THD+N: -105 dB (0.00056%)
Frequency Response: 20 Hz-20 kHz, ±0.1 dB
EIN: -129 dB (A-weighted)
Line Inputs
Dynamic Range: 125 dB (A-weighted)
THD+N: -106 dB (0.0005%)
Frequency Response: 20 Hz-20 kHz, ±0.1 dB
Line Inputs (True Bypass)
Dynamic Range: 126 dB (A-weighted)
THD+N: -113 dB (0.00022%)
Frequency Response: 20 Hz-20 kHz, ±0.1 dB
Instrument Inputs
Dynamic Range: 125 dB (A-weighted)
THD+N: -103 dB (0.0007%)
Frequency Response: 20 Hz-20 kHz, ±0.1 dB
OUTPUTS
DB25 Line Outputs
8 balanced via 25-pin D-sub
Monitor Outputs
2 balanced ¼-inch TRS
Headphone Outputs
4 stereo ¼-inch TRS
Digital Outputs
ADAT: 16 channels @ 44.1-96 kHz
ADAT: 8 channels @ 176.4-192 kHz
D/A CONVERSION
Line Outputs
Dynamic Range: 120 dB (A-weighted)
THD+N: -110 dB (0.0003%)
Frequency Response: 20 Hz-20 kHz, ±0.1 dB
Monitor Outputs
Dynamic Range: 120 dB (A-weighted)
THD+N: -110 dB (0.0003%)
Frequency Response: 20 Hz-20 kHz, ±0.1 dB
Headphone Outputs
Power: 100 mW into 300 ohm; 200 mW into 32 ohm
Dynamic Range: 116 dB (A-weighted)
THD+N (32 ohm): -87 dB (0.0045%)
THD+N (300 ohm): -100 dB (0.001%)
Frequency Response: 20 Hz-20 kHz, ±0.1 dB
DSP ACCELERATION
HDX DSP
8 HDX DSP processors
(2.8 GHz aggregated processing)
WHAT'S INCLUDED
Pro Tools | Carbon audio interface
Pro Tools software
1-year subscription with a Pro Tools perpetual parachute*
116 AAX plugins (over 70 AAX DSP plugins), including UVI Falcon, Celemony Melodyne 5 essential, the Avid Complete Plugin Bundle, and HEAT
3 free months of Antares Auto-Tune Unlimited, including Auto-Tune Hybrid
5.4 GB sound library
Standard support
Included premium plugins
Arturia Rev PLATE-140
Brainworx bx_console N
Brainworx bx_rockrack
Brainworx bx_masterdesk
Brainworx bx_Purple Audio MC77
Embody Immerse Virtual Studio
McDSP 6050 Ultimate Channel Strip HD
Native Instruments Vintage Organs
UVI Model D
Accessories
Power cable
Ethernet cable
Rackmount screws and desktop feet
Registration card
