AVALON  |  SKU: 9096

V5 (Silver)

Pure Class A DI-RE-Microphone Preamplifier


$2,527.00 CAD
Shipping calculated at checkout.

Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

Two alternate solid-state topologies are cascaded to provide a rich, low midrange harmonic content not offered in other Avalon preamplifiers. This feature empowers the V5 with a new scale of sonic character.

Sonic Excellence The Avalon V5 DI-RE-MIC Preamplifer is an ultra-high performance professional preamplifier, DI and RE-amper. Created for maximum versatility, the V5's sonic signature - "Deep and Controlled Bass, Musical Mid-range and enhanced Vocal Projection" combine with a unique set of user features including, 100% discrete Pure Class A amplification, Avalon's unique "passive" TONE-BANK™, professional VU meter with dual peak LED's, multiple outputs including an instrument level transformer isolated Re-amp. Designed to optimize absolute signal integrity and musical performance, the V5 is ideal for ribbon, dynamic and condenser microphones, bass guitar, acoustic instruments, electric guitars, keyboards, synthesizers, and very low output passive pickups.

The state-of-the-art DI input stage provides a very-high inpedance, "zero-load" effect on sensitive pickups and keyboards, while maintaining massive input headroom to +36dB before overload.

Minimum Signal Path Design The V5 includes a very high quality input transformer (same as the Avalon VT-737sp) with dual microphone input impedance loading for perfect mic/cable matching, high-cut switch for eliminating unwanted acoustic pickup and high frequency noise, headphone monitor amp and DC coupled, 100% Class A output amplifiers for defined bass control. A buffered "thru" output for zero-instrument-load tuners or power amp inputs, internal toroid power transformer with discrete high-voltage power supplies for low noise and sealed silver relays for transparent signal routing.

Features

Pure Class A, 100% discrete design

Smooth musical detail and sonic excellence

Variable gain preamp to +30dB.

Dual microphone and line outputs

Hi-Z 3,000,000 ohm input impedance

Very low noise -100dB

High headroom +30dB

Six tone bank selections.

DC coupled Class A output for superior bass

High cut switch eliminates noise

LED active signal indicator

Headphone monitor output jack

Low distortion less than 0.5% THD and IMD

High level 400 watt speaker input

Active to thru selector - ground isolation switch

100% discrete power supplies for audio path

Internal toroidal power supply for low noise

Long lasting, stainless steel hardware

Specifications

Circuit Topology

100% discrete, high-voltage Class A

Gain

Switched 3dB steps, maximum gain +30dB

Input Impedance

3 ,000,000 ohm unbalanced (single ended)

Maximum Input Level

+24dBu unbalanced, 400w speaker input

Output Connectors (2)

XLR type, pin 2 hot electronic balanced

Maximum Output Level (Class A)

+30dBu DC coupled, balanced 600 ohms (mic and line out)

Headphone Output

0.5w into 600 ohms

Noise 20kHz Unweighted

-100dBu minimum gain position

Distortion THD, IMD

0.1% at +10dB

Frequency Response, -/+0.5dB

5Hz to 100kHz

Frequency Response, -3dB

1Hz to 500kHz (input band limited)

High Cut Filter

-3dB at 8kHz minimum phase design

Tone Selector

Six position rotary switch, all passive filters

AC Power

Internal toroidal AC supply

Dimensions

8.5 x 3.5 x 12 in (216 x 88 x 305mm)

Weight-Packed

12lbs (5.4kg)

Rack mount kit (1) RM-1

Single U5 19 inch rack mount kit (holds one half rack unit)

Rack mount kit (2) RM-2

Dual U5 19 inch rack mount kit (holds two half rack units)
