MPN #iD44MKII

$979.00

Save 10.1%, MSRP $1089.00
Financing available
Free shipping in Canada. Conditions

20 In / 24 Out audio interface with four Audient Console mic preamps, ADAT, and ultra-low latency DSP mixer



Audient Console Mic Preamps - The professional sound you deserve
Every iD interface features the Audient Console Mic Preamp, the same discrete circuit design found in our renowned recording console the ASP8024-HE. Designed to deliver ultra-low noise and low distortion with a touch of classic analogue warmth, iD44?s four Audient Console mic preamps will give you the professional sound you deserve.

How does it sound
The Audient mic pre is a high grade hybrid discrete and op amp design that delivers a clean, accurate and detailed translation of your source.

Now that?s quiet
With a noise floor 30,000 times quieter than the signal level your recordings will be captured with stunning clarity.

Class leading converters - Brilliance on the inside enables brilliance on the outside
Offering an incredible 126dB of dynamic range, iD44?s class leading converters have been designed to deliver the most honest and natural translation of your audio, helping you hear subtle detail, identify problematic issues and make better mix decisions. Experience remarkable clarity from the moment you press play.

Even better ADC performance. Just when we thought we couldn?t make the original iD44 sound any better, the MKII sees a massive 9dB improvement on the ADC?s THD+N figure, meaning clean audio with less added noise and even less audible distortion.

Expand via ADAT - More channels, more possibilities
Easily configure your studio to tackle bigger sessions. Equipped with two optical input and output connectors, iD44 gives you plenty of options for expansion. Supporting both ADAT and SPDIF, boost your I/O by adding up to 16 channels of mic preamps to your setup.

Balanced Inserts - Hardware Integration
Integrate your favourite outboard FX prior to conversion and start creating signal chains that rival the very best. The insert returns also gives you direct access to the A/D converters providing the cleanest signal path possible, making it great for print-backs or integrating outboard line level sources.

Plug and play
Designed to replicate the input stage of a classic valve amplifier, iD44 features two harmonically rich JFET Instrument Inputs giving you the perfect sonic foundation for your guitars or basses before you hit your amp sims.

Speaker Outputs
Connect and listen to your mixes through two sets of speakers with iD44?s four line outputs. Alternatively use the extra line outputs to send audio to an external headphone amp for distribution to your artists.

Headphone Outputs
Easily record and collaborate with others by utilising iD44?s two individual stereo headphone amps, both providing more than enough power for your headphones to perform accurately.

Lost your headphone adapter or need a third set of headphones iD44 now benefits from the addition of a dual headphone output, including both a ¼? jack and a mini-jack, on headphone output one, providing even more monitoring flexibility when you need it.

Audio Loop-back - Creativity unleashed
Now equipped with Audio Loop-back, iD44 can quickly transform into a multi-purpose powerhouse. Giving you the ability to capture playback from multiple applications on your computer at the same time as your microphones, Audio Loop-back lets you create a custom audio feed ready to send to your streaming software. Ideal for content creators, podcasters and streamers.

What is Audio Loop-back
Audio loopback is becoming an increasingly in-demand feature due to the prevalent rise of podcasting, Youtube/content creators and gaming streamers. Check out our comprehensive guide to Audio Loop-back.

Software Mixer - Experience ultra-low latency
The iD mixer tightly integrates hardware and software, letting you effortlessly set up low latency direct monitoring, create up to four stereo artist cue mixes, name and customise channels, save layout presets, assign hardware function buttons and quickly setup advanced routing. iD44?s Loop-back feature is also controlled via the Software Mixer, enabling you to select the Loop-back source from 6 different options to suit a variety of practical scenarios. Endless possibilities, speedy workflow.

Talkback - Innovation meets communication
iD44?s dedicated talkback technology enables you to use any audio source connected to your computer such as a built-in or USB microphone as your talkback mic, freeing up valuable mic preamps for recording.

Made for music
Reliable performance, a simple layout and a delightfully intuitive user experience let you focus on doing what you do best, making music. We can?t wait to hear what you create.

Console Style Monitor Control - Work faster
Speed up your workflow with iD44?s three programmable function buttons. Assign any of the advanced monitoring features, including Speaker Select, Mono Sum, Polarity Reverse or Cue Mix monitoring, to any of the F-buttons and quickly take control of your session.

ScrollControl - The virtual scroll wheel
Turn iD44?s volume knob into a virtual scroll wheel and take control of a variety of compatible onscreen parameters. Quickly dial in settings, adjust faders or even write in automation without spending hours staring at the screen.

USB2.0 - Make a connection
iD44 comes with both a standard USB Type-A cable and a USB Type-C cable enabling you to connect to any USB compatible Mac or PC supporting USB 2.0 or above.

All-Metal Construction - Built to last
With its all-metal construction, hand finished aluminium knobs and high grade component selection, iD44 delivers professional quality audio in a beautifully engineered and simple package.

Create instantly
Bundled with a free suite of creative software including Cubase LE and Cubasis LE for iOS, alongside industry leading plugins and virtual instruments, you can start recording as soon as you open the box
  • 4 x Class-A Audient Console Mic Preamplifiers
  • Class Leading AD/DA Converters
  • 2 x Discrete JFET Instrument Inputs
  • Main and Alt Speaker Outputs
  • 1 x Independent Headphone Output
  • 1 x Independent Dual Headphone Output
  • 2 x ADAT Inputs & Outputs for Digital Expansion
  • 2 x Fully Balanced Inserts
  • Ultra-low Latency DSP Mixer
  • Audio Loop-back
  • ScrollControl
  • 3 x User Defined Function Keys
  • Dedicated Talkback, Dim and Cut Controls
  • +48V, Pad, and HPF Switches
  • USB 2.0 Compliant
  • Standalone Mode
  • 24bit/96kHz
  • Word Clock Output
  • Power switch
  • All-Metal Design
  • Free Software + Plugins
  • Microphone preamplifier
  • MIC GAIN: 0 to +60 dB
  • LINE GAIN: -10 to +50 dB
  • PHANTOM POWER: 48v +/-4v @ 10mA/Channel (12VDC only)
  • MIC EIN: -126dBu
  • CMRR: >80dB @ 1kHz
  • MAXIMUM INPUT LEVEL: +18 dBu
  • INPUT IMPEDANCE (Mic): 3k ? balanced
  • INPUT IMPEDANCE (Line): 10k ? balanced
  • FREQUENCY RESPONSE: ±0.5 dB 10Hz to 65kHz
  • CROSSTALK: <-90 dBu @ 1kHz & 10kHz
  • THD+N @ 0dBu (1kHz): 0.003% (-96dBu)
  • SNR: 96dB
  • XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
  • 1/4? TRS JACK: TIP (Hot), RING (Cold) & SLEEVE (Shield)

  • D.I / Instrument Input (Channel 1):
  • D.I GAIN: 0 to +60 dB
  • MAXIMUM INPUT LEVEL: +10dBu
  • INPUT IMPEDANCE: 1Meg? Unbalanced
  • FREQUENCY RESPONSE: ±0.5 dB 10Hz to 50kHz
  • THD+N @ 0dBu (1kHz): <0.3%
  • SNR: 95dB A-weighted
  • 1/4? JACK: Tip (Hot) & Sleeve (Shield)

  • Analogue to Digital Converter (ADC 1 & 2):
    (Measured via Insert Returns under AES-17)
  • MAXIMUM INPUT LEVEL: +18 dBu (0 dBFS digital maximum)
  • DIGITAL REFERENCE LEVEL: +18 dBu = 0 dBFS
  • INPUT IMPEDANCE: >10k ? Balanced
  • CROSSTALK: -115 dBu @ 1kHz & 10kHz
  • FREQUENCY RESPONSE: ±0.5 dB 10Hz to Fs/2 (Nyquist)
  • CROSSTALK: -115dBu @ 1kHz & 10kHz
  • THD+N @ -1dBFS (1kHz): <0.0003% (-112dB)
  • DYNAMIC RANGE: 120 dB A-weighted
  • 1/4? TRS JACK: TIP (Hot), RING (Cold) & SLEEVE (Shield)

  • Digital to Analogue Converter (DAC 1 & 2):
    (Measured under AES-17 at line outputs 1 & 2)
  • MAXIMUM INPUT LEVEL: +18 dBu (0 dBFS digital maximum)
  • DIGITAL REFERENCE LEVEL: +18 dBu = 0 dBFS
  • OUTPUT IMPEDANCE: <100 ?
  • CROSSTALK: <-118 dBu @ 1kHz & 10kHz
  • FREQUENCY RESPONSE: ±0.5 dB 10Hz to Fs/2 (Nyquist)
  • CROSSTALK: -115dBu @ 1kHz & 10kHz
  • THD+N @ -1dBFS (1kHz): <0.0006% (-104dB)
  • DYNAMIC RANGE: 124 dB un-weighted, 126 dB A-weighted
  • 1/4? TRS JACK: TIP (Hot), RING (Cold) & SLEEVE (Shield)

  • Headphone Outputs:
    (Measured under AES-17 at phones output)
  • MAXIMUM OUTPUT LEVEL: +14 dBu (0 dBFS digital maximum)
  • DIGITAL REFERENCE LEVEL: +14 dBu = 0 dBFS
  • OUTPUT IMPEDANCE: <50 ? unbalanced
  • CROSSTALK: <-110 dBu @ 1kHz & 10kHz
  • FREQUENCY RESPONSE: ±0.5dB 10Hz to Fs/2
  • CROSSTALK: -115dBu @ 1kHz & 10kHz
  • THD+N @ -1dBFS (1kHz): <0.0008% (-103 dB)
  • DYNAMIC RANGE: 121 dB un-weighted, 124 dB A-weighted
  • MAX LEVEL INTO 30ohms: +10.2 dBu 0.002% THD+N Power: 210mW
  • MAX LEVEL INTO 60ohms: +14.2 dBu 0.001% THD+N Power: 54mW
  • MAX LEVEL INTO 600ohms: +14.2 dBu 0.001% THD+N Power: 54mW
  • 1/4? JACK: TIP (Hot), RING (Cold) & SLEEVE (Shield)

  • Digital Input:
  • ADAT 16 CHANNELS: 44.1kHz to 48.0kHz
  • ADAT 8 CHANNELS (SMUX): 88.2kHz to 96.0kHz
  • STEREO S/PDIF: 44.1kHz to 96.0kHz

  • USB2.0 High Speed:
  • No. of INPUT CHANNELS 20: 20 (4 Analogue, 16 Digital)
  • No. of OUTPUT CHANNELS 24: 24 (8 Analogue, 16 Digital)
  • Connector: USB Type-C
  • Included Cables: 1.5m USB 2.0 Type-C to USB Type-C, 1.5m USB 2.0 Type-C to USB Type-A

  • DSP Mixer Latency " ROUND TRIP (in-to-out):
  • 44.1kHz 0.677ms
  • 48.0kHz 0.625ms
  • 88.2kHz 0.354ms
  • 96.0kHz 0.323ms

  • Dimensions:
  • Unit: 276mm (w) x 51mm (h) x 174mm (d)
