Allen & Heath QU-SB
MPN #QU-SB
$1749.00
Save 14.6%, MSRP $2049.00
Compact digital mixer offering remote wireless control, versatile connectivity, and advanced processing for live sound and studio applications.
Qu-SB is an ultra-compact digital mixer which frees you to mix from anywhere in the venue and provides a smart, portable solution for performing bands and artists.
Qu-SB is portable enough to carry under one arm and comes loaded with our highly acclaimed suite of FX emulations and dynamics, making it a smart replacement for an old analogue mixer and a rack full of outboard FX.
REMOTE CONTROL APPS
Having massive processing power and advanced functionality is great, but it counts for nothing if you can't access the controls you need in a heartbeat.
Qu-SB is designed to integrate seaamlessly with the fully-featured Qu-Pad iPad app, providing super-fast, easy access to all settings, including channel processing, meters and RTA views, FX racks, scene management, USB audio control, setup menus and much more.
CAPTURE EVERY DETAIL
Qu has been designed from the ground up to deliver professional sound quality, from input to output.
Qu-SB features sixteen AnalogiQ digitally controlled preamps with advanced zero-crossing detection and a padless 1dB-step gain stage.
The AnalogiQ preamp design has been refined to offer superb transparency, minimal distortion and an ultra-low noise floor, with a warm, musical sound that is missing from some digital consoles.
The analogue signal is captured by high-class, low latency 24bit analogue to digital converters, which are matched to 24bit digital to analogue converters to deliver the required high quality output.
WORLD CLASS PROCESSING & FX
Qu's RackFX dynamics and FX algorithms are derived from those used in our pro touring series.
Some of the world's most respected audio engineers have chosen to use RackFX on tour in preference to top-end plug-ins and external FX units.
Qu boasts 4 stereo RackFX engines, featuring lovingly crafted emulations of legendary classic reverbs, gated reverbs, delays, modulators, flangers and more. FX are returned to the mix on dedicated return channels, so you're not tying up your mono and stereo input channels, and each Stereo FX Return has a dedicated 4 band PEQ.
RECORD. STREAM. MIX.
Qu's built-in interface streams multitrack audio to your Mac or PC via a flexible patching system: all Input channels and the Main LR can be recorded at the same time, or you may choose to record something different such as FX returns or a pair of mixes.
The returns from the computer can be assigned to the Input channels. The interface is class-compliant on Mac OS X - and drivers are available for Windows systems. Either way, it will be recognized straightaway by any DAW supporting ASIOTM or Core Audio, including Logic, Cubase, Reaper, and Pro Tools.
Standard MIDI control is tunnelled over the USB and network connections, this can be mapped to the faders of your favourite DAW using the A&H MIDI Control app which provides easy setup and emulation of HUI or Mackie Control protocols on Mac OS X and Windows systems.
Want to livestream Easy. Just send a stereo mix over USB and your streaming software will do the rest.
EVERYTHING I/O
Qu-SB is a self-contained mixer, so if you've already got the analogue cables you're good to go.
But if you're thinking of trading in the multicore for a Cat5 digital snake, the built-in dSNAKE port has you future-proofed, allowing connection to a remote AB168, AR2412 or AR84 Stagebox from our Everything I/O range of remote expanders.
Qu-Drive: Record without a computer
Qu-SB has an integrated multitrack USB recorder, providing 18 channels of 48kHz, 24bit recording and playback straight to / from your USB key or hard drive.
Capturing multitrack recordings of your shows has never been so easy. A selectable stereo pair can be recorded alongside the 16 Mono channels, and multitrack audio can be played back to the 16 Mono inputs plus ST1.
On top of this, Qu-Drive also provides stereo recording patchable from any pair of Mix outputs, the Main LR (pre, post, or summed to mono) or even the PAFL bus, with 2- track stereo playback to ST3.
AMM: Automatic Mic Mixer
AMM is vital in applications such as conferences, meetings and panel discussions where a number of microphones are open at the same time.
Reducing background noise and minimising the risk of feedback, the Automatic Microphone Mixer helps the engineer to manage the levels of multiple mic inputs, ensuring that each speaker's contribution is heard clearly.
The D-Classic dynamic gain sharing algorithm is inspired by industry standard automixers. Up to 16 microphone sources can be mixed at once, with each channel having a priority setting which determines its ?weight' in the total system gain.
Features
Inputs: 16 Mono / 1 StereoExpandable to 32 mono / 3 stereoMixes: 4 Mono / 4 Stereo / LRExpandable to 4 Mono / 7 Stereo / LRMatrix: 2 Stereo32x32 USB Audio InterfaceComprehensive Channel Processing and FXRange of Remote Expanders
Suitable for:
LiveStudioStreamingA/V InstallCorporate AudioHouses of Worship
Specifications
Inputs: 16 recallable AnalogiQ mic/line preamps; 3 stereo TRS line inputsOutputs: 12 mix outputs; main LR outputs; 2-track output; AES digital outProcessing Channels: 32 mono and 3 stereo DSP channels; 4 FX engines with dedicated returnsRemote Control: Full control via Qu-Pad iPad app over Wi-Fi; compatible with Allen & Heath's ME personal monitoring systemUSB Interface: 32x32 USB recording interface; supports multitrack recording and playbackExpansion: dSNAKE port for remote audio racks (e.g., AB168, AR2412) and personal monitoring systemsConstruction: Rack-mountable, faderless design; compact and portable for easy transport and setupDimensions: Width: 13.4 inches (340 mm); Depth: 6.9 inches (175 mm); Height: 5.1 inches (130 mm)Weight: Approximately 7.7 lbs (3.5 kg)
