ALLEN & HEATH  |  SKU: 24181

AHM-32

Management System

32-32 matrix, 12-12 analog I/O, AEC module, Dante/SLink expansion, 96kHz core, 8 SoftKeys, AMM, ANC, ducking, GPIO, remote control, Crestron/AMX ready

$2,765.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The Allen & Heath AHM-32 offers powerful audio processing for larger, more complex environments such as hotels, universities, and corporate buildings. With its expansive 32-32 matrix and 12-12 local analog I/O, it provides granular control and routing for multiple audio zones. Each of the 32 outputs can be configured as a mono or stereo zone or used for precise speaker processing.

Built around a 96kHz FPGA core, the AHM-32 ensures ultra-low latency performance. It features robust tools for system optimization, including four automatic mic mixers, ambient noise compensation (ANC), priority ducking, and comprehensive EQ and dynamics on every input and output. For conferencing applications, it supports an optional AEC module delivering up to 12 channels of acoustic echo cancellation.

Connectivity is future-proofed with an audio networking I/O port compatible with Dante, MADI, Waves, or SLink cards. On the front panel, users benefit from a clear display and eight programmable SoftKeys for quick access to key functions like source selection and preset recall. The AHM-32 integrates easily with IP remote controllers and third-party systems (Crestron, AMX, Extron), offering scalable control via desktop or mobile apps, making it an ideal hub for flexible and intelligent sound management.

Features

Powerful 32-32 Matrix: Fully configurable signal routing and processing across 32 input and 32 output paths.

12-12 Local Analog I/O: Features 12 mic/line inputs and 12 relay-protected outputs via Phoenix connectors.

Expandable via Networking: Supports Dante, MADI, Waves, and SLink expansion cards (up to 128-128 channels).

Advanced Zone Processing: Each input and output includes 8-band PEQ, dynamics, and delay, plus speaker tuning tools.

Acoustic Echo Cancellation (AEC): Optional 12-channel AEC module ideal for conferencing and AV installations.

Smart Audio Control Tools: Includes 4 auto mic mixers, ambient noise compensation, priority ducking, and EQ ganging.

Front Panel Control: Equipped with a display and 8 programmable SoftKeys for easy access to key functions.

Comprehensive Remote Options: Works with IP1, IP6, IP8 controllers, Custom Control app, and major third-party protocols.

Built-In Automation: Offers event scheduling and integrated stereo playback functionality.

High-Speed Core: Ultra-low latency 96kHz FPGA core delivers clean, fast audio processing.

Scalable and Secure: Supports up to 16 user profiles with flexible access and control options.

Specifications

Signal Processing

32-32 processing matrix

Configurable mono/stereo zones or speaker processing

4x automatic mic mixers

Acoustic Echo Cancellation (AEC) - 12 channels (for teleconferencing/videoconferencing)

Ambient Noise Compensation (ANC)

Priority ducking

8-band PEQ, dynamics, and delay on all inputs and outputs

Output speaker processing: crossover filters, delay, limiter, PEQ, and all-pass filters

EQ ganging: Relative, Absolute, and Mirrored controls

Inputs & Outputs

12x mic/line inputs (Phoenix connectors)

12x relay-protected line outputs (Phoenix connectors)

2-2 local GPIO

Audio networking I/O port (up to 128-128 channels)

Optional networking cards: Dante (96kHz, AES67, DDM ready), MADI, Waves, SLink

Hardware Features

96kHz FPGA core with ultra-low latency

Front panel display with navigation

8x programmable SoftKeys

Integrated stereo playback

Event scheduler

16 user profiles

Remote Control & Integration

Compatible with IP1, IP6, IP8 remote controllers

TCP/IP protocol for third-party integration

Networkable GPIO interface support

Crestron, AMX, and Extron control drivers

Custom Control app and editor for BYOD

Mac and Windows AHM System Manager software

Application Scope

Designed for medium to large multi-room installations

Suitable for hospitality, corporate, and educational environments

Ideal for AV conferencing setups with AEC support
